Opel Zafira Specs, Engines & Dimensions (2016–2019)

Opel Zafira Engines and Transmissions

Opel Zafira engine choices in this generation keep a front-wheel-drive drivetrain, with petrol, LPG and diesel powertrains as selected examples. The 1.6 AT gasoline automatic is the relaxed daily option, while the 1.4 MT LPG and 2.0 MT diesel manuals let you choose fuel and a more involved transmission.

Minivan — Opel Zafira Engines and Transmissions

Minivan Opel Zafira Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1364 cm³	120 hp	88 kW	200 N⋅m	Manual	FWD
1.4 MT	Gasoline	1364 cm³	140 hp	103 kW	200 N⋅m	Manual	FWD
1.6 AT	Gasoline	1598 cm³	170 hp	125 kW	260 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1598 cm³	200 hp	147 kW	280 N⋅m	Manual	FWD
1.4 MT	LPG	1364 cm³	140 hp	103 kW	200 N⋅m	Manual	FWD
1.6 MT	LPG	1598 cm³	150 hp	110 kW	210 N⋅m	Manual	FWD
2.0 AT	Diesel	1956 cm³	130 hp	96 kW	300 N⋅m	Automatic	FWD
2.0 AT	Diesel	1956 cm³	170 hp	125 kW	400 N⋅m	Automatic	FWD
2.0 MT	Diesel	1956 cm³	170 hp	125 kW	400 N⋅m	Manual	FWD
1.4 AT	Gasoline	1364 cm³	140 hp	103 kW	200 N⋅m	Automatic	FWD

Opel Zafira Dimensions

Minivan — Opel Zafira Dimensions

Minivan Opel Zafira Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4666 mm	1884 mm	1660 mm	2760 mm	1628 kg	2285 kg	160 mm
1.4 MT	4666 mm	1884 mm	1660 mm	2760 mm	1628 kg	2285 kg	160 mm
1.6 AT	4666 mm	1884 mm	1660 mm	2760 mm	1701 kg	2370 kg	160 mm
1.6 MT	4666 mm	1884 mm	1660 mm	2760 mm	1664 kg	2335 kg	160 mm
1.4 MT	4666 mm	1884 mm	1660 mm	2760 mm	1679 kg	2330 kg	160 mm
1.6 MT	4666 mm	1884 mm	1660 mm	2760 mm	1716 kg	2355 kg	160 mm
2.0 AT	4666 mm	1884 mm	1660 mm	2760 mm	1788 kg	2450 kg	160 mm
2.0 AT	4666 mm	1884 mm	1660 mm	2760 mm	1803 kg	2470 kg	160 mm
2.0 MT	4666 mm	1884 mm	1660 mm	2760 mm	1748 kg	2455 kg	160 mm
1.4 AT	4666 mm	1884 mm	1660 mm	2760 mm	1628 kg	2315 kg	160 mm

Opel Zafira Cargo Space

Minivan — Opel Zafira Cargo Space

Minivan Opel Zafira Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	152 l	1860 l
1.4 MT	152 l	1860 l
1.6 AT	152 l	1860 l
1.6 MT	152 l	1860 l
1.4 MT	152 l	1860 l
1.6 MT	152 l	1860 l
2.0 AT	152 l	1860 l
2.0 AT	152 l	1860 l
2.0 MT	152 l	1860 l
1.4 AT	152 l	1860 l

Opel Zafira Trims and Equipment

Opel Zafira trim levels describe the equipment packed around a given technical version, not a different engine. On the 1.4 AT gasoline automatic minivan with front-wheel drive, Enjoy is the named configuration, so you are choosing cabin and convenience features on that automatic setup rather than a new powertrain.

Opel Zafira Trims and Equipment
Modification	Body	Equipment
1.4 AT	Minivan	Enjoy
