Opel Zafira Specs, Engines & Dimensions (1999–2004)

Opel Zafira Engines and Transmissions

An Opel Zafira engine in this generation came as petrol or diesel, with a manual or automatic transmission. The 2.2 MT gasoline compact van is one front-wheel-drive example; the 2.0 AT diesel automatic and 2.2 MT diesel manual show other everyday powertrain mixes, not the full lineup.

Compact Van — Opel Zafira Engines and Transmissions

Compact Van Opel Zafira Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	97 hp	71 kW	140 N⋅m	Manual	FWD
1.6 MT	Gasoline	1598 cm³	101 hp	74 kW	150 N⋅m	Manual	FWD
1.8 MT	Gasoline	1796 cm³	116 hp	85 kW	170 N⋅m	Manual	FWD
1.8 AT	Gasoline	1796 cm³	116 hp	85 kW	170 N⋅m	Automatic	FWD
2.2 MT	Gasoline	2198 cm³	147 hp	108 kW	203 N⋅m	Manual	FWD
2.0 MT	Diesel	1995 cm³	82 hp	60 kW	185 N⋅m	Manual	FWD
2.2 MT	Diesel	2171 cm³	125 hp	92 kW	280 N⋅m	Manual	FWD
1.8 MT	Gasoline	1796 cm³	125 hp	92 kW	170 N⋅m	Manual	FWD
1.8 AT	Gasoline	1796 cm³	125 hp	92 kW	170 N⋅m	Automatic	FWD
2.2 AT	Gasoline	2198 cm³	147 hp	108 kW	203 N⋅m	Automatic	FWD
2.0 MT	Diesel	1995 cm³	101 hp	74 kW	230 N⋅m	Manual	FWD
2.0 AT	Diesel	1995 cm³	101 hp	74 kW	205 N⋅m	Automatic	FWD

Opel Zafira Dimensions

Compact Van — Opel Zafira Dimensions

Compact Van Opel Zafira Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4315 mm	1740 mm	1630 mm	2694 mm	1485 kg	2085 kg	150 mm
1.6 MT	4315 mm	1740 mm	1630 mm	2694 mm	1320 kg	1950 kg	150 mm
1.8 MT	4315 mm	1740 mm	1630 mm	2694 mm	1360 kg	1960 kg	150 mm
1.8 AT	4315 mm	1740 mm	1630 mm	2694 mm	1360 kg	1960 kg	150 mm
2.2 MT	4315 mm	1740 mm	1630 mm	2694 mm	1400 kg	2000 kg	150 mm
2.0 MT	4315 mm	1740 mm	1630 mm	2694 mm	1445 kg	2045 kg	150 mm
2.2 MT	4315 mm	1740 mm	1630 mm	2694 mm	1550 kg	2075 kg	150 mm
1.8 MT	4315 mm	1740 mm	1630 mm	2694 mm	1370 kg	1960 kg	150 mm
1.8 AT	4315 mm	1740 mm	1630 mm	2694 mm	1370 kg	1960 kg	150 mm
2.2 AT	4315 mm	1740 mm	1630 mm	2694 mm	1385 kg	2040 kg	150 mm
2.0 MT	4315 mm	1740 mm	1630 mm	2694 mm	1485 kg	2085 kg	150 mm
2.0 AT	4315 mm	1740 mm	1630 mm	2694 mm	1495 kg	2020 kg	150 mm

Opel Zafira Cargo Space

Compact Van — Opel Zafira Cargo Space

Compact Van Opel Zafira Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	150 l	1700 l
1.6 MT	150 l	1700 l
1.8 MT	150 l	1700 l
1.8 AT	150 l	1700 l
2.2 MT	150 l	1700 l
2.0 MT	150 l	1700 l
2.2 MT	150 l	1700 l
1.8 MT	150 l	1700 l
1.8 AT	150 l	1700 l
2.2 AT	150 l	1700 l
2.0 MT	150 l	1700 l
2.0 AT	150 l	1700 l

Opel Zafira Trims and Equipment

Opel Zafira trim levels describe the equipment fitted to a given technical version. On the 2.2 AT gasoline automatic compact van, that package is named Base. Treat Base as the kit on that front-wheel-drive example, not as a separate engine or a full list of every trim.

Opel Zafira Trims and Equipment
Modification	Body	Equipment
1.8 MT	Compact Van	Base
1.8 AT	Compact Van	Base
2.2 AT	Compact Van	Base
2.0 MT	Compact Van	Base
2.0 AT	Compact Van	Base
