Mitsubishi Mirage Specs, Engines & Dimensions (1983–1988) — Second Generation

You will find the second-generation Mitsubishi Mirage as a Sedan, Hatchback 3-door or Hatchback 5-door, compact city cars with mixed gasoline and diesel powertrains.

← All Mitsubishi models

Mitsubishi Mirage Engines and Transmissions

You can match a Mitsubishi Mirage engine to how you drive: compact gasoline or diesel units sending power through a front-wheel drivetrain. Examples include the 1.3 AT and 1.5 AT Hatchback 3-door gasoline automatics, plus the 1.8 MT Hatchback 5-door diesel with a manual transmission.

Sedan — Mitsubishi Mirage Engines and Transmissions

Sedan Mitsubishi Mirage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 MT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Manual	FWD
1.3 AT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Automatic	FWD
1.5 AT	Gasoline	1468 cm³	73 hp	54 kW	119 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Manual	FWD
1.5 AT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Automatic	FWD
1.5 AT	Gasoline	1499 cm³	82 hp	60 kW	125 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Manual	FWD
1.3 MT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Manual	FWD
1.3 AT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1468 cm³	73 hp	54 kW	119 N⋅m	Manual	FWD
1.5 MT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Manual	FWD
1.5 MT	Gasoline	1499 cm³	82 hp	60 kW	125 N⋅m	Manual	FWD
1.8 MT	Diesel	1796 cm³	61 hp	45 kW	113 N⋅m	Manual	FWD
1.8 MT	Diesel	1796 cm³	65 hp	48 kW	113 N⋅m	Manual	FWD

Hatchback 3-door — Mitsubishi Mirage Engines and Transmissions

Hatchback 3-door Mitsubishi Mirage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 MT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Manual	FWD
1.3 MT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Manual	FWD
1.3 AT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1468 cm³	73 hp	54 kW	119 N⋅m	Manual	FWD
1.5 MT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Manual	FWD
1.5 AT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Manual	FWD
1.5 MT	Gasoline	1499 cm³	82 hp	60 kW	125 N⋅m	Manual	FWD
1.6 MT	Gasoline	1597 cm³	105 hp	77 kW	165 N⋅m	Manual	FWD
1.6 MT	Gasoline	1597 cm³	120 hp	88 kW	172 N⋅m	Manual	FWD

Hatchback 5-door — Mitsubishi Mirage Engines and Transmissions

Hatchback 5-door Mitsubishi Mirage Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 MT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Manual	FWD
1.3 MT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Manual	FWD
1.3 AT	Gasoline	1299 cm³	67 hp	49 kW	106 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Manual	FWD
1.3 AT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1299 cm³	77 hp	57 kW	108 N⋅m	Manual	FWD
1.5 MT	Gasoline	1468 cm³	73 hp	54 kW	119 N⋅m	Manual	FWD
1.5 AT	Gasoline	1468 cm³	73 hp	54 kW	119 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Manual	FWD
1.5 AT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1468 cm³	87 hp	64 kW	123 N⋅m	Manual	FWD
1.5 MT	Gasoline	1499 cm³	82 hp	60 kW	125 N⋅m	Manual	FWD
1.5 AT	Gasoline	1499 cm³	82 hp	60 kW	125 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1597 cm³	120 hp	88 kW	172 N⋅m	Manual	FWD
1.6 AT	Gasoline	1597 cm³	120 hp	88 kW	172 N⋅m	Automatic	FWD
1.8 MT	Diesel	1796 cm³	65 hp	48 kW	113 N⋅m	Manual	FWD

Mitsubishi Mirage Dimensions

Sedan — Mitsubishi Mirage Dimensions

Sedan Mitsubishi Mirage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.3 MT	4125 mm	1620 mm	1360 mm	2380 mm	820 kg	Not provided	150 mm
1.3 AT	4125 mm	1620 mm	1360 mm	2380 mm	840 kg	Not provided	150 mm
1.5 AT	4125 mm	1620 mm	1360 mm	2380 mm	880 kg	Not provided	150 mm
1.5 MT	4125 mm	1620 mm	1360 mm	2380 mm	820 kg	Not provided	150 mm
1.5 AT	4125 mm	1620 mm	1360 mm	2380 mm	840 kg	Not provided	150 mm
1.5 AT	4125 mm	1620 mm	1360 mm	2380 mm	910 kg	Not provided	150 mm
1.3 MT	4125 mm	1620 mm	1360 mm	2380 mm	820 kg	1095 kg	150 mm
1.3 MT	4125 mm	1620 mm	1360 mm	2380 mm	800 kg	Not provided	150 mm
1.3 AT	4125 mm	1620 mm	1360 mm	2380 mm	820 kg	Not provided	150 mm
1.5 MT	4125 mm	1620 mm	1360 mm	2380 mm	860 kg	1135 kg	150 mm
1.5 MT	4125 mm	1620 mm	1360 mm	2380 mm	840 kg	Not provided	150 mm
1.5 MT	4125 mm	1620 mm	1360 mm	2380 mm	900 kg	1175 kg	150 mm
1.8 MT	4125 mm	1620 mm	1360 mm	2380 mm	920 kg	1195 kg	150 mm
1.8 MT	4125 mm	1620 mm	1360 mm	2380 mm	910 kg	Not provided	150 mm

Hatchback 3-door — Mitsubishi Mirage Dimensions

Hatchback 3-door Mitsubishi Mirage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.3 MT	3870 mm	1620 mm	1360 mm	2380 mm	800 kg	Not provided	150 mm
1.3 MT	3870 mm	1620 mm	1360 mm	2380 mm	775 kg	Not provided	150 mm
1.3 AT	3870 mm	1620 mm	1360 mm	2380 mm	815 kg	Not provided	150 mm
1.5 MT	3870 mm	1620 mm	1360 mm	2380 mm	860 kg	1135 kg	150 mm
1.5 MT	3870 mm	1620 mm	1360 mm	2380 mm	790 kg	Not provided	150 mm
1.5 AT	3870 mm	1620 mm	1360 mm	2380 mm	850 kg	Not provided	150 mm
1.5 MT	3870 mm	1620 mm	1360 mm	2380 mm	845 kg	1115 kg	150 mm
1.5 MT	3870 mm	1620 mm	1360 mm	2380 mm	890 kg	1165 kg	150 mm
1.6 MT	3870 mm	1620 mm	1360 mm	2380 mm	910 kg	1185 kg	150 mm
1.6 MT	3870 mm	1620 mm	1360 mm	2380 mm	880 kg	Not provided	150 mm

Hatchback 5-door — Mitsubishi Mirage Dimensions

Hatchback 5-door Mitsubishi Mirage Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.3 MT	3870 mm	1635 mm	1360 mm	2380 mm	820 kg	Not provided	150 mm
1.3 MT	3870 mm	1635 mm	1360 mm	2380 mm	820 kg	Not provided	150 mm
1.3 AT	3870 mm	1635 mm	1360 mm	2380 mm	840 kg	Not provided	150 mm
1.3 MT	3870 mm	1635 mm	1360 mm	2380 mm	810 kg	Not provided	150 mm
1.3 AT	3870 mm	1635 mm	1360 mm	2380 mm	830 kg	Not provided	150 mm
1.3 MT	3870 mm	1635 mm	1360 mm	2380 mm	810 kg	Not provided	150 mm
1.5 MT	3870 mm	1635 mm	1360 mm	2380 mm	860 kg	Not provided	150 mm
1.5 AT	3870 mm	1635 mm	1360 mm	2380 mm	880 kg	Not provided	150 mm
1.5 MT	3870 mm	1635 mm	1360 mm	2380 mm	820 kg	Not provided	150 mm
1.5 AT	3870 mm	1635 mm	1360 mm	2380 mm	840 kg	Not provided	150 mm
1.5 MT	3870 mm	1635 mm	1360 mm	2380 mm	840 kg	1115 kg	150 mm
1.5 MT	3870 mm	1635 mm	1360 mm	2380 mm	890 kg	Not provided	150 mm
1.5 AT	3870 mm	1635 mm	1360 mm	2380 mm	910 kg	Not provided	150 mm
1.6 MT	3870 mm	1635 mm	1360 mm	2380 mm	900 kg	1175 kg	150 mm
1.6 AT	3870 mm	1635 mm	1360 mm	2380 mm	910 kg	1185 kg	150 mm
1.8 MT	3870 mm	1635 mm	1360 mm	2380 mm	920 kg	1195 kg	150 mm
