Catalog / Mitsubishi / Mirage / 1 generation
Mitsubishi Mirage Engines and Transmissions
You will find a Mitsubishi Mirage engine here as a compact gasoline unit. Sedan examples include the 1.2 MT with a manual gearbox and the 1.4 AT with automatic, both front-wheel drive. The Hatchback 3-door 1.2 MT uses that same simple powertrain; these drivetrain pairings are selected examples, not the full lineup.
Sedan — Mitsubishi Mirage Engines and Transmissions
Sedan Mitsubishi Mirage Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.2 MT Gasoline 1244 cm³ 72 hp 53 kW 105 N⋅m Manual FWD 1.4 MT Gasoline 1411 cm³ 82 hp 60 kW 119 N⋅m Manual FWD 1.4 AT Gasoline 1411 cm³ 82 hp 60 kW 119 N⋅m Automatic FWD 1.4 MT Gasoline 1411 cm³ 105 hp 77 kW 152 N⋅m Manual FWD
Hatchback 3-door — Mitsubishi Mirage Engines and Transmissions
Hatchback 3-door Mitsubishi Mirage Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.2 MT Gasoline 1244 cm³ 72 hp 53 kW 105 N⋅m Manual FWD 1.2 AT Gasoline 1244 cm³ 72 hp 53 kW 105 N⋅m Automatic FWD 1.4 MT Gasoline 1411 cm³ 82 hp 60 kW 119 N⋅m Manual FWD 1.4 AT Gasoline 1411 cm³ 82 hp 60 kW 119 N⋅m Automatic FWD 1.4 MT Gasoline 1411 cm³ 105 hp 77 kW 152 N⋅m Manual FWD 1.6 MT Gasoline 1597 cm³ 88 hp 65 kW 132 N⋅m Manual FWD
Hatchback 5-door — Mitsubishi Mirage Engines and Transmissions
Hatchback 5-door Mitsubishi Mirage Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.2 MT Gasoline 1244 cm³ 72 hp 53 kW 105 N⋅m Manual FWD 1.4 MT Gasoline 1411 cm³ 82 hp 60 kW 119 N⋅m Manual FWD 1.4 AT Gasoline 1411 cm³ 82 hp 60 kW 119 N⋅m Automatic FWD 1.4 MT Gasoline 1411 cm³ 105 hp 77 kW 152 N⋅m Manual FWD 1.6 MT Gasoline 1597 cm³ 88 hp 65 kW 132 N⋅m Manual FWD
Mitsubishi Mirage Dimensions
Sedan — Mitsubishi Mirage Dimensions
Sedan Mitsubishi Mirage Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
1.2 MT 4105 mm 1590 mm 1350 mm 2380 mm 800 kg 170 mm 1.4 MT 4105 mm 1590 mm 1350 mm 2380 mm 820 kg 170 mm 1.4 AT 4105 mm 1590 mm 1350 mm 2380 mm 820 kg 170 mm 1.4 MT 4105 mm 1590 mm 1350 mm 2380 mm 885 kg 170 mm
Hatchback 3-door — Mitsubishi Mirage Dimensions
Hatchback 3-door Mitsubishi Mirage Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.2 MT 3790 mm 1585 mm 1350 mm 2300 mm 760 kg 1250 kg 170 mm 1.2 AT 3790 mm 1585 mm 1350 mm 2300 mm 815 kg 1250 kg 170 mm 1.4 MT 3790 mm 1585 mm 1350 mm 2300 mm 820 kg 1250 kg 170 mm 1.4 AT 3790 mm 1585 mm 1350 mm 2300 mm 850 kg 1250 kg 170 mm 1.4 MT 3790 mm 1585 mm 1350 mm 2300 mm 820 kg 1095 kg 170 mm 1.6 MT 3790 mm 1585 mm 1350 mm 2300 mm 840 kg 1250 kg 170 mm
Hatchback 5-door — Mitsubishi Mirage Dimensions
Hatchback 5-door Mitsubishi Mirage Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.2 MT 3895 mm 1585 mm 1350 mm 2380 mm 790 kg 1295 kg 170 mm 1.4 MT 3895 mm 1585 mm 1350 mm 2380 mm 820 kg 1295 kg 170 mm 1.4 AT 3895 mm 1585 mm 1350 mm 2380 mm 880 kg 1295 kg 170 mm 1.4 MT 3895 mm 1585 mm 1350 mm 2380 mm 860 kg 1295 kg 170 mm 1.6 MT 3895 mm 1585 mm 1350 mm 2380 mm 860 kg 1295 kg 170 mm
Mitsubishi Mirage Cargo Space
Hatchback 3-door — Mitsubishi Mirage Cargo Space
