Catalog / Mitsubishi / Carisma / 1 generation
Mitsubishi Carisma Engines and Transmissions
Among the Mitsubishi Carisma engine choices, the 1.9 MT sedan and five-door hatchback offer a diesel powertrain with a manual transmission and front-wheel drive. A diesel can suit regular longer journeys, while the manual gearbox lets you select a lower gear when you need extra response for hills or overtaking.
Sedan — Mitsubishi Carisma Engines and Transmissions
Sedan Mitsubishi Carisma Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 AT Gasoline 1597 cm³ 100 hp 73 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 100 hp 73 kW 137 N⋅m Manual FWD 1.8 MT Gasoline 1834 cm³ 116 hp 85 kW 162 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 116 hp 85 kW 162 N⋅m Automatic FWD 1.8 MT Gasoline 1834 cm³ 125 hp 92 kW 174 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 125 hp 92 kW 174 N⋅m Automatic FWD 1.8 AT Gasoline 1834 cm³ 140 hp 103 kW 181 N⋅m Automatic FWD 1.8 MT Gasoline 1834 cm³ 140 hp 103 kW 167 N⋅m Manual FWD 1.9 MT Diesel 1870 cm³ 90 hp 66 kW 176 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Manual FWD
Hatchback 5-door — Mitsubishi Carisma Engines and Transmissions
Hatchback 5-door Mitsubishi Carisma Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 AT Gasoline 1597 cm³ 100 hp 73 kW 137 N⋅m Automatic FWD 1.8 MT Gasoline 1834 cm³ 116 hp 85 kW 162 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 116 hp 85 kW 162 N⋅m Automatic FWD 1.8 MT Gasoline 1834 cm³ 140 hp 103 kW 167 N⋅m Manual FWD 1.6 MT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 100 hp 73 kW 137 N⋅m Manual FWD 1.8 MT Gasoline 1834 cm³ 125 hp 92 kW 174 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 125 hp 92 kW 174 N⋅m Automatic FWD 1.9 MT Diesel 1870 cm³ 90 hp 66 kW 176 N⋅m Manual FWD
Mitsubishi Carisma Dimensions
Sedan — Mitsubishi Carisma Dimensions
Sedan Mitsubishi Carisma Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 AT 4435 mm 1710 mm 1405 mm 2550 mm 1140 kg 1660 kg 150 mm 1.6 MT 4435 mm 1710 mm 1405 mm 2550 mm 1105 kg 1630 kg 150 mm 1.8 MT 4435 mm 1710 mm 1405 mm 2550 mm 1130 kg 1660 kg 150 mm 1.8 AT 4435 mm 1710 mm 1405 mm 2550 mm Not provided 1660 kg 150 mm 1.8 MT 4435 mm 1710 mm 1405 mm 2550 mm 1140 kg 1665 kg 150 mm 1.8 AT 4435 mm 1710 mm 1405 mm 2550 mm 1140 kg 1685 kg 150 mm 1.8 AT 4435 mm 1710 mm 1405 mm 2550 mm 1200 kg Not provided 150 mm 1.8 MT 4435 mm 1710 mm 1405 mm 2550 mm 1175 kg 1685 kg 150 mm 1.9 MT 4435 mm 1710 mm 1405 mm 2550 mm 1145 kg 1675 kg 150 mm 1.6 AT 4435 mm 1710 mm 1405 mm 2550 mm Not provided 1610 kg 150 mm 1.6 MT 4435 mm 1710 mm 1405 mm 2550 mm 1080 kg 1610 kg 150 mm
Hatchback 5-door — Mitsubishi Carisma Dimensions
Hatchback 5-door Mitsubishi Carisma Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 AT 4445 mm 1710 mm 1405 mm 2550 mm 1140 kg 1660 kg 150 mm 1.8 MT 4445 mm 1710 mm 1405 mm 2550 mm 1130 kg 1660 kg 150 mm 1.8 AT 4445 mm 1710 mm 1405 mm 2550 mm Not provided 1660 kg 150 mm 1.8 MT 4445 mm 1710 mm 1405 mm 2550 mm 1175 kg 1685 kg 150 mm 1.6 MT 4445 mm 1710 mm 1405 mm 2550 mm 1270 kg 1630 kg 150 mm 1.6 AT 4445 mm 1710 mm 1405 mm 2550 mm 1140 kg 1630 kg 150 mm 1.6 MT 4445 mm 1710 mm 1405 mm 2550 mm 1110 kg 1630 kg 150 mm 1.8 MT 4445 mm 1710 mm 1405 mm 2550 mm 1165 kg 1685 kg 150 mm 1.8 AT 4445 mm 1710 mm 1405 mm 2550 mm 1165 kg 1685 kg 150 mm 1.9 MT 4445 mm 1710 mm 1405 mm 2550 mm 1150 kg 1675 kg 150 mm
Mitsubishi Carisma Cargo Space
Sedan — Mitsubishi Carisma Cargo Space
Hatchback 5-door — Mitsubishi Carisma Cargo Space
