Catalog / Mitsubishi / Carisma / 1 generation, restyling
Mitsubishi Carisma Engines and Transmissions
Mitsubishi Carisma engine choices include the gasoline 1.3 MT sedan, while the gasoline 1.8 MT and 1.8 AT five-door hatchbacks illustrate manual and automatic options. These examples all have front-wheel drive. A manual lets you choose gears directly for hills and overtaking, while an automatic reduces your workload in stop-start traffic.
Sedan — Mitsubishi Carisma Engines and Transmissions
Sedan Mitsubishi Carisma Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.3 MT Gasoline 1299 cm³ 82 hp 60 kW 120 N⋅m Manual FWD 1.6 MT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 99 hp 73 kW 137 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 99 hp 73 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 103 hp 76 kW 141 N⋅m Manual FWD 1.8 MT Gasoline 1834 cm³ 122 hp 90 kW 174 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 122 hp 90 kW 174 N⋅m Automatic FWD 1.8 MT Gasoline 1834 cm³ 125 hp 92 kW 174 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 125 hp 92 kW 174 N⋅m Automatic FWD 1.9 MT Diesel 1870 cm³ 102 hp 75 kW 215 N⋅m Manual FWD 1.9 MT Diesel 1870 cm³ 115 hp 85 kW 265 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 103 hp 76 kW 141 N⋅m Automatic FWD
Hatchback 5-door — Mitsubishi Carisma Engines and Transmissions
Hatchback 5-door Mitsubishi Carisma Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 AT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 90 hp 66 kW 137 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 99 hp 73 kW 137 N⋅m Automatic FWD 1.6 MT Gasoline 1597 cm³ 99 hp 73 kW 137 N⋅m Manual FWD 1.6 MT Gasoline 1597 cm³ 103 hp 76 kW 141 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 103 hp 76 kW 141 N⋅m Automatic FWD 1.8 MT Gasoline 1834 cm³ 122 hp 90 kW 174 N⋅m Manual FWD 1.8 AT Gasoline 1834 cm³ 122 hp 90 kW 174 N⋅m Automatic FWD 1.9 MT Diesel 1870 cm³ 90 hp 66 kW 176 N⋅m Manual FWD 1.9 MT Diesel 1870 cm³ 102 hp 75 kW 215 N⋅m Manual FWD 1.9 MT Diesel 1870 cm³ 115 hp 85 kW 265 N⋅m Manual FWD
Mitsubishi Carisma Dimensions
Sedan — Mitsubishi Carisma Dimensions
Sedan Mitsubishi Carisma Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.3 MT 4475 mm 1710 mm 1405 mm 2550 mm 1170 kg 1675 kg 150 mm 1.6 MT 4475 mm 1710 mm 1405 mm 2550 mm 1080 kg 1610 kg 150 mm 1.6 AT 4475 mm 1710 mm 1405 mm 2550 mm Not provided 1610 kg 150 mm 1.6 MT 4475 mm 1710 mm 1405 mm 2550 mm 1155 kg 1665 kg 155 mm 1.6 AT 4475 mm 1710 mm 1405 mm 2550 mm 1185 kg 1695 kg 155 mm 1.6 MT 4475 mm 1710 mm 1405 mm 2550 mm 1185 kg 1695 kg 150 mm 1.8 MT 4475 mm 1710 mm 1405 mm 2550 mm 1215 kg 1725 kg 150 mm 1.8 AT 4475 mm 1710 mm 1405 mm 2550 mm Not provided 1725 kg 150 mm 1.8 MT 4475 mm 1710 mm 1405 mm 2550 mm 1140 kg 1665 kg 150 mm 1.8 AT 4475 mm 1710 mm 1405 mm 2550 mm 1165 kg 1685 kg 150 mm 1.9 MT 4475 mm 1710 mm 1405 mm 2550 mm 1265 kg 1775 kg 150 mm 1.9 MT 4475 mm 1710 mm 1405 mm 2550 mm 1265 kg 1775 kg 150 mm 1.6 AT 4475 mm 1710 mm 1405 mm 2550 mm Not provided 1695 kg 150 mm
Hatchback 5-door — Mitsubishi Carisma Dimensions
Hatchback 5-door Mitsubishi Carisma Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.6 AT 4475 mm 1710 mm 1405 mm 2550 mm 1140 kg 1630 kg 150 mm 1.6 MT 4475 mm 1710 mm 1405 mm 2550 mm 1080 kg 1610 kg 150 mm 1.6 AT 4475 mm 1710 mm 1405 mm 2550 mm 1205 kg 1715 kg 150 mm 1.6 MT 4475 mm 1710 mm 1405 mm 2550 mm 1175 kg 1685 kg 155 mm 1.6 MT 4475 mm 1710 mm 1405 mm 2550 mm 1205 kg 1715 kg 150 mm 1.6 AT 4475 mm 1710 mm 1405 mm 2550 mm Not provided 1715 kg 150 mm 1.8 MT 4475 mm 1710 mm 1405 mm 2550 mm 1260 kg 1750 kg 150 mm 1.8 AT 4475 mm 1710 mm 1405 mm 2550 mm Not provided 1750 kg 150 mm 1.9 MT 4475 mm 1710 mm 1405 mm 2550 mm 1285 kg 1795 kg 150 mm 1.9 MT 4475 mm 1710 mm 1405 mm 2550 mm 1285 kg 1795 kg 150 mm 1.9 MT 4475 mm 1710 mm 1405 mm 2550 mm 1285 kg 1795 kg 150 mm
Mitsubishi Carisma Cargo Space
Sedan — Mitsubishi Carisma Cargo Space
Hatchback 5-door — Mitsubishi Carisma Cargo Space
