Mercedes GLA Specs, Engines & Dimensions (2013–2017)

Mercedes GLA Engines and Transmissions

Among the Mercedes GLA engine choices, the gasoline GLA180 1.6 MT gives you manual control, while the diesel GLA180d 1.5 DCT handles shifts through a dual-clutch transmission. Both use front-wheel drive. The gasoline GLA250 2.0 DCT 4Matic combines dual-clutch shifting with all-wheel drive, which can help you pull away on slippery surfaces.

SUV 5-doors — Mercedes GLA Engines and Transmissions

SUV 5-doors Mercedes GLA Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
GLA200 1.6 DCT	Gasoline	1595 cm³	150 hp	110 kW	250 N⋅m	Robotic	FWD
GLA180 1.6 MT	Gasoline	1595 cm³	122 hp	90 kW	200 N⋅m	Manual	FWD
GLA180 1.6 DCT	Gasoline	1595 cm³	122 hp	90 kW	200 N⋅m	Robotic	FWD
GLA200 1.6 MT	Gasoline	1595 cm³	150 hp	110 kW	250 N⋅m	Manual	FWD
GLA200 1.6 MT	Gasoline	1595 cm³	156 hp	115 kW	250 N⋅m	Manual	FWD
GLA250 2.0 DCT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Robotic	FWD
GLA180d 1.5 DCT	Diesel	1461 cm³	109 hp	80 kW	260 N⋅m	Robotic	FWD
GLA180d 1.5 MT	Diesel	1461 cm³	109 hp	80 kW	260 N⋅m	Manual	FWD
GLA200d 2.1 MT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Manual	FWD
GLA200d 2.1 DCT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Robotic	FWD
GLA220d 2.1 DCT	Diesel	2143 cm³	170 hp	125 kW	350 N⋅m	Robotic	FWD
GLA200d 2.1 DCT 4Matic	Diesel	2143 cm³	170 hp	125 kW	350 N⋅m	Robotic	AWD
GLA200d 2.1 DCT 4Matic	Diesel	2143 cm³	177 hp	130 kW	350 N⋅m	Robotic	AWD
GLA250 2.0 DCT 4Matic	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Robotic	AWD
GLA200 1.6 DCT	Gasoline	1595 cm³	156 hp	115 kW	250 N⋅m	Robotic	FWD
GLA200d 2.1 DCT 4Matic	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Robotic	AWD

Mercedes GLA Dimensions

SUV 5-doors — Mercedes GLA Dimensions

SUV 5-doors Mercedes GLA Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
GLA200 1.6 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1435 kg	1920 kg	Not provided
GLA180 1.6 MT	4417 mm	1804 mm	1494 mm	2699 mm	1395 kg	1920 kg	154 mm
GLA180 1.6 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1435 kg	1920 kg	154 mm
GLA200 1.6 MT	4417 mm	1804 mm	1494 mm	2699 mm	1395 kg	1920 kg	154 mm
GLA200 1.6 MT	4417 mm	1804 mm	1494 mm	2699 mm	1395 kg	1920 kg	154 mm
GLA250 2.0 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1455 kg	1940 kg	154 mm
GLA180d 1.5 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1470 kg	1960 kg	154 mm
GLA180d 1.5 MT	4417 mm	1804 mm	1494 mm	2699 mm	1440 kg	1960 kg	154 mm
GLA200d 2.1 MT	4417 mm	1804 mm	1494 mm	2699 mm	1505 kg	2020 kg	154 mm
GLA200d 2.1 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1595 kg	2075 kg	154 mm
GLA220d 2.1 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1535 kg	2020 kg	154 mm
GLA200d 2.1 DCT 4Matic	4417 mm	1804 mm	1494 mm	2699 mm	1595 kg	2075 kg	154 mm
GLA200d 2.1 DCT 4Matic	4417 mm	1804 mm	1494 mm	2699 mm	1595 kg	2075 kg	154 mm
GLA250 2.0 DCT 4Matic	4417 mm	1804 mm	1494 mm	2699 mm	1505 kg	1990 kg	154 mm
GLA200 1.6 DCT	4417 mm	1804 mm	1494 mm	2699 mm	1435 kg	1920 kg	Not provided
GLA200d 2.1 DCT 4Matic	4417 mm	1804 mm	1494 mm	2699 mm	1595 kg	2075 kg	154 mm

Mercedes GLA Cargo Space

SUV 5-doors — Mercedes GLA Cargo Space

SUV 5-doors Mercedes GLA Cargo Space
Modification	Trunk volume min	Trunk volume max
GLA200 1.6 DCT	421 l	1235 l
GLA180 1.6 MT	421 l	1235 l
GLA180 1.6 DCT	421 l	1235 l
GLA200 1.6 MT	421 l	1235 l
GLA200 1.6 MT	421 l	1235 l
GLA250 2.0 DCT	421 l	1235 l
GLA180d 1.5 DCT	421 l	1235 l
GLA180d 1.5 MT	421 l	1235 l
GLA200d 2.1 MT	421 l	1235 l
GLA200d 2.1 DCT	421 l	1235 l
GLA220d 2.1 DCT	421 l	1235 l
GLA200d 2.1 DCT 4Matic	421 l	1235 l
GLA200d 2.1 DCT 4Matic	421 l	1235 l
GLA250 2.0 DCT 4Matic	421 l	1235 l
GLA200 1.6 DCT	421 l	1235 l
GLA200d 2.1 DCT 4Matic	421 l	1235 l

Mercedes GLA Trims and Equipment

Mercedes GLA trim levels describe equipment choices alongside the powertrain specification. The GLA250 2.0 DCT 4Matic has configurations named GLA 250 4Matic Special Series and Urban. When comparing examples, check the individual car’s seats, climate controls and parking aids: the version name alone does not establish every feature fitted.

Mercedes GLA Trims and Equipment
Modification	Body	Equipment
GLA200 1.6 DCT	SUV 5-doors	GLA 250 4Matic Special Series
GLA200d 2.1 DCT	SUV 5-doors	Urban
GLA250 2.0 DCT 4Matic	SUV 5-doors	GLA 250 4Matic Special Series
GLA250 2.0 DCT 4Matic	SUV 5-doors	Urban
GLA250 2.0 DCT 4Matic	SUV 5-doors	Urban Plus
GLA250 2.0 DCT 4Matic	SUV 5-doors	Offroad
GLA250 2.0 DCT 4Matic	SUV 5-doors	AMG Plus
GLA250 2.0 DCT 4Matic	SUV 5-doors	AMG
GLA200 1.6 DCT	SUV 5-doors	Urban
GLA200 1.6 DCT	SUV 5-doors	Urban Plus
GLA200 1.6 DCT	SUV 5-doors	Style Plus
GLA200 1.6 DCT	SUV 5-doors	AMG
GLA200d 2.1 DCT 4Matic	SUV 5-doors	Urban
GLA200d 2.1 DCT 4Matic	SUV 5-doors	Offroad
