Catalog / Mercedes / A-Class / 2 generation
Mercedes A-Class Engines and Transmissions
A typical Mercedes A-Class engine here is a small four-cylinder, either gasoline as in the A150 1.5 MT and A150 1.5 CVT, or turbodiesel as in the A160CDI 2.0 CVT. Diesel favours economy on longer trips; gasoline stays quieter around town. Every drivetrain sends power to the front wheels.
Mini 5-doors — Mercedes A-Class Engines and Transmissions
Mini 5-doors Mercedes A-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
A150 1.5 MT Gasoline 1498 cm³ 95 hp 70 kW 140 N⋅m Manual FWD A150 1.5 CVT Gasoline 1498 cm³ 95 hp 70 kW 140 N⋅m Variable FWD A170 1.7 MT Gasoline 1699 cm³ 116 hp 85 kW 155 N⋅m Manual FWD A170 1.7 CVT Gasoline 1699 cm³ 116 hp 85 kW 155 N⋅m Variable FWD A200 2.0 MT Gasoline 2034 cm³ 136 hp 100 kW 185 N⋅m Manual FWD A200 2.0 CVT Gasoline 2034 cm³ 136 hp 100 kW 185 N⋅m Variable FWD A200 Turbo 2.0 MT Gasoline 2034 cm³ 193 hp 142 kW 280 N⋅m Manual FWD A200 Turbo 2.0 CVT Gasoline 2034 cm³ 193 hp 142 kW 280 N⋅m Variable FWD A160CDI 2.0 MT Diesel 1991 cm³ 82 hp 60 kW 180 N⋅m Manual FWD A160CDI 2.0 CVT Diesel 1991 cm³ 82 hp 60 kW 180 N⋅m Variable FWD A180CDI 2.0 MT Diesel 1991 cm³ 109 hp 80 kW 250 N⋅m Manual FWD A180CDI 2.0 CVT Diesel 1991 cm³ 109 hp 80 kW 250 N⋅m Variable FWD A200CDI 2.0 MT Diesel 1991 cm³ 140 hp 103 kW 300 N⋅m Manual FWD A200CDI 2.0 CVT Diesel 1991 cm³ 140 hp 103 kW 300 N⋅m Variable FWD
Mini 3-doors — Mercedes A-Class Engines and Transmissions
Mercedes A-Class Dimensions
Mini 5-doors — Mercedes A-Class Dimensions
Mini 5-doors Mercedes A-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
A150 1.5 MT 3838 mm 1764 mm 1593 mm 2568 mm 1155 kg 1690 kg 110 mm A150 1.5 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1205 kg 1690 kg 110 mm A170 1.7 MT 3838 mm 1764 mm 1593 mm 2568 mm 1170 kg 1705 kg 110 mm A170 1.7 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1210 kg 1705 kg 110 mm A200 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1200 kg 1695 kg 110 mm A200 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1245 kg 1695 kg 110 mm A200 Turbo 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1235 kg 1730 kg 110 mm A200 Turbo 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1305 kg 1780 kg 110 mm A160CDI 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1255 kg 1760 kg 110 mm A160CDI 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1300 kg 1760 kg 110 mm A180CDI 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1275 kg 1770 kg 110 mm A180CDI 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1310 kg 1770 kg 110 mm A200CDI 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1295 kg 1780 kg 110 mm A200CDI 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1325 kg 1780 kg 110 mm
Mini 3-doors — Mercedes A-Class Dimensions
Mini 3-doors Mercedes A-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
A150 1.5 MT 3838 mm 1764 mm 1593 mm 2568 mm 1155 kg 1690 kg 110 mm A150 1.5 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1205 kg 1690 kg 110 mm A170 1.7 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1210 kg 1705 kg 110 mm A200 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1200 kg 1695 kg 110 mm A200 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1245 kg 1695 kg 110 mm A200 Turbo 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1235 kg 1730 kg 110 mm A200 Turbo 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1305 kg 1780 kg 110 mm A160CDI 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1255 kg 1760 kg 110 mm A180CDI 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1310 kg 1770 kg 110 mm A200CDI 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1295 kg 1780 kg 110 mm A170 1.7 MT 3838 mm 1764 mm 1593 mm 2568 mm 1170 kg 1705 kg 110 mm A160CDI A160CDI 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1300 kg 1760 kg 110 mm A180CDI 2.0 MT 3838 mm 1764 mm 1593 mm 2568 mm 1275 kg 1770 kg 110 mm A200CDI 2.0 CVT 3838 mm 1764 mm 1593 mm 2568 mm 1325 kg 1780 kg 110 mm
Mercedes A-Class Cargo Space
Mini 5-doors — Mercedes A-Class Cargo Space
Mini 3-doors — Mercedes A-Class Cargo Space
