Catalog / Mazda / Axela / 3 generation, restyling
Mazda Axela Engines and Transmissions
The Mazda Axela engine range spans economical petrol units and torquier diesels. A 1.5 AT sedan with automatic transmission and front-wheel drive suits city commuting, while the same 1.5 AT is also offered with all-wheel drive. The 2.2 MT diesel pairs manual shifting with strong mid-range pull.
Sedan — Mazda Axela Engines and Transmissions
Sedan Mazda Axela Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic AWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 210 N⋅m Automatic AWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic FWD
Hatchback 5-door — Mazda Axela Engines and Transmissions
Hatchback 5-door Mazda Axela Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic AWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 210 N⋅m Automatic AWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic FWD
Mazda Axela Dimensions
Sedan — Mazda Axela Dimensions
Sedan Mazda Axela Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.5 AT 4580 mm 1795 mm 1455 mm 2700 mm 1190 kg 1835 kg 155 mm 1.5 AT 4580 mm 1795 mm 1455 mm 2700 mm Not provided 1835 kg 155 mm 2.0 AT 4580 mm 1795 mm 1455 mm 2700 mm 1320 kg 1835 kg 155 mm 2.0 AT 4580 mm 1795 mm 1455 mm 2700 mm Not provided 1835 kg 155 mm 2.2 MT 4580 mm 1795 mm 1455 mm 2700 mm 1395 kg 1910 kg 155 mm 2.2 AT 4580 mm 1795 mm 1455 mm 2700 mm 1405 kg 1930 kg 155 mm
Hatchback 5-door — Mazda Axela Dimensions
Hatchback 5-door Mazda Axela Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.5 AT 4460 mm 1795 mm 1450 mm 2700 mm 1190 kg 1835 kg 155 mm 1.5 AT 4460 mm 1795 mm 1450 mm 2700 mm Not provided 1835 kg 155 mm 2.0 AT 4460 mm 1795 mm 1450 mm 2700 mm 1320 kg 1835 kg 155 mm 2.0 AT 4460 mm 1795 mm 1450 mm 2700 mm Not provided 1835 kg 155 mm 2.2 MT 4460 mm 1795 mm 1450 mm 2700 mm 1395 kg 1910 kg 155 mm 2.2 AT 4460 mm 1795 mm 1450 mm 2700 mm 1405 kg 1930 kg 155 mm
Mazda Axela Cargo Space
Sedan — Mazda Axela Cargo Space
Hatchback 5-door — Mazda Axela Cargo Space
Hatchback 5-door Mazda Axela Cargo Space Modification Trunk volume min Trunk volume max
1.5 AT 350 l 1250 l 1.5 AT 350 l 1250 l 2.0 AT 350 l 1250 l 2.0 AT 350 l 1250 l 2.2 MT 350 l 1250 l 2.2 AT 350 l 1250 l
