Mazda 626 Specs, Engines & Dimensions (1991–1997) — Fourth Generation

The fourth-generation Mazda 626 offers Sedan, Estate 5-door and Hatchback 5-door body styles, letting you weigh passenger space and luggage access alongside the powertrain that suits your everyday driving.

← All Mazda models

Mazda 626 Engines and Transmissions

Mazda 626 engine choices include the Sedan’s gasoline 1.8 AT, pairing an automatic transmission with front-wheel drive to reduce effort in traffic. Other Sedan examples include the diesel 2.0 MT with manual gear selection and front-wheel drive, and the gasoline 2.0 AT with an automatic and all-wheel drive, which can help traction on slippery roads.

Sedan — Mazda 626 Engines and Transmissions

Sedan Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1840 cm³	90 hp	66 kW	143 N⋅m	Manual	FWD
1.8 MT	Gasoline	1840 cm³	105 hp	65 kW	155 N⋅m	Manual	FWD
1.8 AT	Gasoline	1840 cm³	105 hp	77 kW	155 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1991 cm³	115 hp	71 kW	170 N⋅m	Manual	FWD
2.0 AT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Manual	AWD
2.0 MT	Diesel	1998 cm³	75 hp	46 kW	169 N⋅m	Manual	FWD

Estate 5-door — Mazda 626 Engines and Transmissions

Estate 5-door Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 AT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Manual	FWD
2.0 MT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Manual	AWD
2.0 MT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Manual	FWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	FWD
2.0 MT	Diesel	1998 cm³	75 hp	55 kW	169 N⋅m	Manual	FWD

Hatchback 5-door — Mazda 626 Engines and Transmissions

Hatchback 5-door Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1800 cm³	90 hp	66 kW	Not provided	Manual	FWD
1.8 AT	Gasoline	1800 cm³	90 hp	66 kW	Not provided	Automatic	FWD
1.8 MT	Gasoline	1840 cm³	105 hp	65 kW	155 N⋅m	Manual	FWD
1.8 AT	Gasoline	1840 cm³	105 hp	77 kW	155 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1991 cm³	115 hp	71 kW	170 N⋅m	Manual	FWD
2.0 AT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Automatic	AWD
2.0 MT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Manual	AWD
2.5 MT	Gasoline	2497 cm³	163 hp	101 kW	217 N⋅m	Manual	FWD
2.5 AT	Gasoline	2497 cm³	163 hp	101 kW	217 N⋅m	Automatic	FWD
2.5 MT	Gasoline	2497 cm³	165 hp	101 kW	217 N⋅m	Manual	FWD
2.5 AT	Gasoline	2497 cm³	165 hp	101 kW	217 N⋅m	Automatic	FWD
2.0 MT	Diesel	1998 cm³	75 hp	46 kW	169 N⋅m	Manual	FWD
2.0 AT	Gasoline	1991 cm³	115 hp	85 kW	170 N⋅m	Automatic	FWD

Mazda 626 Dimensions

Sedan — Mazda 626 Dimensions

Sedan Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4695 mm	1750 mm	1400 mm	2610 mm	1150 kg	1675 kg	160 mm
1.8 MT	4695 mm	1750 mm	1400 mm	2610 mm	1150 kg	1645 kg	160 mm
1.8 AT	4695 mm	1750 mm	1400 mm	2610 mm	1175 kg	1645 kg	160 mm
2.0 MT	4695 mm	1750 mm	1400 mm	2610 mm	1150 kg	1645 kg	160 mm
2.0 AT	4695 mm	1750 mm	1400 mm	2610 mm	Not provided	Not provided	160 mm
2.0 AT	4695 mm	1750 mm	1400 mm	2610 mm	Not provided	1645 kg	160 mm
2.0 MT	4695 mm	1750 mm	1400 mm	2610 mm	Not provided	Not provided	160 mm
2.0 MT	4695 mm	1750 mm	1400 mm	2610 mm	1265 kg	1710 kg	160 mm

Estate 5-door — Mazda 626 Dimensions

Estate 5-door Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 AT	4600 mm	1690 mm	1465 mm	2575 mm	Not provided	Not provided	160 mm
2.0 AT	4600 mm	1690 mm	1465 mm	2575 mm	Not provided	1780 kg	160 mm
2.0 MT	4600 mm	1690 mm	1465 mm	2575 mm	1230 kg	1780 kg	160 mm
2.0 MT	4600 mm	1690 mm	1465 mm	2575 mm	Not provided	Not provided	160 mm
2.0 MT	4600 mm	1690 mm	1465 mm	2575 mm	1205 kg	1760 kg	160 mm
2.2 MT	4600 mm	1690 mm	1465 mm	2575 mm	Not provided	Not provided	155 mm
2.0 MT	4600 mm	1690 mm	1465 mm	2575 mm	1305 kg	1840 kg	160 mm

Hatchback 5-door — Mazda 626 Dimensions

Hatchback 5-door Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4695 mm	1750 mm	1390 mm	2610 mm	Not provided	Not provided	160 mm
1.8 AT	4695 mm	1750 mm	1390 mm	2610 mm	Not provided	Not provided	160 mm
1.8 MT	4695 mm	1750 mm	1390 mm	2610 mm	1180 kg	1675 kg	160 mm
1.8 AT	4695 mm	1750 mm	1390 mm	2610 mm	1205 kg	1675 kg	160 mm
2.0 MT	4695 mm	1750 mm	1390 mm	2610 mm	1185 kg	1675 kg	160 mm
2.0 AT	4695 mm	1750 mm	1390 mm	2610 mm	Not provided	Not provided	160 mm
2.0 MT	4695 mm	1750 mm	1390 mm	2610 mm	Not provided	Not provided	160 mm
2.5 MT	4695 mm	1750 mm	1390 mm	2610 mm	1275 kg	1735 kg	160 mm
2.5 AT	4695 mm	1750 mm	1390 mm	2610 mm	1275 kg	1735 kg	160 mm
2.5 MT	4695 mm	1750 mm	1390 mm	2610 mm	1275 kg	1735 kg	160 mm
2.5 AT	4695 mm	1750 mm	1390 mm	2610 mm	1275 kg	1735 kg	160 mm
2.0 MT	4695 mm	1750 mm	1390 mm	2610 mm	1265 kg	1710 kg	160 mm
2.0 AT	4695 mm	1750 mm	1390 mm	2610 mm	Not provided	1675 kg	160 mm

Mazda 626 Cargo Space

Sedan — Mazda 626 Cargo Space

Sedan Mazda 626 Cargo Space
Modification	Trunk volume min
1.8 MT	452 l
1.8 MT	452 l
1.8 AT	452 l
2.0 MT	452 l
2.0 AT	452 l
2.0 AT	452 l
2.0 MT	452 l
2.0 MT	452 l

Estate 5-door — Mazda 626 Cargo Space

Estate 5-door Mazda 626 Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 AT	430 l	1315 l
2.0 AT	430 l	1315 l
2.0 MT	430 l	1315 l
2.0 MT	430 l	1315 l
2.0 MT	430 l	1315 l
2.2 MT	430 l	1315 l
2.0 MT	430 l	1315 l

Hatchback 5-door — Mazda 626 Cargo Space

Hatchback 5-door Mazda 626 Cargo Space
Modification	Trunk volume min
1.8 MT	747 l
1.8 AT	747 l
1.8 MT	747 l
1.8 AT	747 l
2.0 MT	747 l
2.0 AT	747 l
2.0 MT	747 l
2.5 MT	747 l
2.5 AT	747 l
2.5 MT	747 l
2.5 AT	747 l
2.0 MT	747 l
2.0 AT	747 l
