Mazda 626 Specs, Engines & Dimensions (1987–1996) — Third Generation

The third-generation Mazda 626 spans coupe, sedan, estate and five-door hatchback bodies. Beyond choosing the shape that suits your space needs, consider how the engine, transmission and driven wheels fit your everyday journeys.

← All Mazda models

Mazda 626 Engines and Transmissions

Selected Mazda 626 engine choices include the gasoline 2.2 AT Coupe with front-wheel drive, diesel 2.0 MT Sedan with front-wheel drive, and gasoline 2.2 AT Sedan with all-wheel drive. An automatic transmission eases driving in traffic, while a manual gives you direct gear control. All-wheel drive can help you pull away on slippery surfaces, though tyre grip remains important.

Coupe — Mazda 626 Engines and Transmissions

Coupe Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 AT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Automatic	FWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Manual	FWD
2.0 AT	Gasoline	2000 cm³	107 hp	79 kW	Not provided	Automatic	FWD
2.0 MT	Gasoline	2000 cm³	107 hp	79 kW	Not provided	Manual	FWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	FWD

Sedan — Mazda 626 Engines and Transmissions

Sedan Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 AT	Gasoline	1800 cm³	88 hp	65 kW	Not provided	Automatic	FWD
2.0 AT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Automatic	FWD
2.0 AT	Gasoline	2000 cm³	107 hp	79 kW	Not provided	Automatic	FWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	AWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	AWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1800 cm³	88 hp	65 kW	Not provided	Manual	FWD
2.0 MT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	90 hp	66 kW	150 N⋅m	Manual	FWD
2.0 MT	Gasoline	2000 cm³	107 hp	79 kW	Not provided	Manual	FWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	FWD
2.0 MT	Diesel	1998 cm³	60 hp	44 kW	128 N⋅m	Manual	FWD
2.0 AT	Diesel	1998 cm³	60 hp	44 kW	128 N⋅m	Automatic	FWD

Estate 5-door — Mazda 626 Engines and Transmissions

Estate 5-door Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 AT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Automatic	FWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	AWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	FWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	FWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	AWD
2.0 MT	Diesel	1998 cm³	60 hp	44 kW	128 N⋅m	Manual	FWD
2.0 MT	Diesel	1998 cm³	75 hp	55 kW	169 N⋅m	Manual	FWD

Hatchback 5-door — Mazda 626 Engines and Transmissions

Hatchback 5-door Mazda 626 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 MT	Gasoline	1800 cm³	88 hp	65 kW	Not provided	Manual	FWD
1.8 AT	Gasoline	1800 cm³	88 hp	65 kW	Not provided	Automatic	FWD
2.0 AT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1995 cm³	140 hp	103 kW	186 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	90 hp	66 kW	150 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	90 hp	66 kW	153 N⋅m	Automatic	FWD
2.0 MT	Gasoline	2000 cm³	107 hp	79 kW	Not provided	Manual	FWD
2.0 AT	Gasoline	2000 cm³	107 hp	79 kW	Not provided	Automatic	FWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	FWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	AWD
2.2 MT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Manual	AWD
2.2 AT	Gasoline	2184 cm³	115 hp	85 kW	180 N⋅m	Automatic	FWD
2.0 MT	Diesel	1998 cm³	60 hp	44 kW	128 N⋅m	Manual	FWD

Mazda 626 Dimensions

Coupe — Mazda 626 Dimensions

Coupe Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
2.0 AT	4550 mm	1690 mm	1410 mm	2580 mm	Not provided	155 mm
2.0 AT	4550 mm	1690 mm	1410 mm	2580 mm	Not provided	155 mm
2.2 AT	4550 mm	1690 mm	1410 mm	2580 mm	Not provided	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	1175 kg	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	1110 kg	155 mm
2.0 AT	4550 mm	1690 mm	1410 mm	2580 mm	Not provided	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	1090 kg	155 mm
2.2 MT	4550 mm	1690 mm	1410 mm	2580 mm	1130 kg	155 mm

Sedan — Mazda 626 Dimensions

Sedan Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.0 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.0 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.0 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.2 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.2 MT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.2 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
1.8 MT	4534 mm	1689 mm	1410 mm	2576 mm	1090 kg	Not provided	155 mm
2.0 MT	4534 mm	1689 mm	1410 mm	2576 mm	1205 kg	Not provided	155 mm
2.0 MT	4534 mm	1689 mm	1410 mm	2576 mm	1125 kg	1840 kg	155 mm
2.0 MT	4534 mm	1689 mm	1410 mm	2576 mm	1115 kg	Not provided	155 mm
2.2 MT	4534 mm	1689 mm	1410 mm	2576 mm	1150 kg	1840 kg	155 mm
2.0 MT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm
2.0 AT	4534 mm	1689 mm	1410 mm	2576 mm	Not provided	Not provided	155 mm

Estate 5-door — Mazda 626 Dimensions

Estate 5-door Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
2.0 AT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.0 AT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.2 AT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.2 AT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.2 MT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.2 MT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm
2.0 MT	4550 mm	1690 mm	1410 mm	2580 mm	155 mm

Hatchback 5-door — Mazda 626 Dimensions

Hatchback 5-door Mazda 626 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 MT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
1.8 AT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.0 AT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.0 MT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.0 MT	4534 mm	1689 mm	1374 mm	2576 mm	1145 kg	1840 kg	155 mm
2.0 MT	4534 mm	1689 mm	1374 mm	2576 mm	1145 kg	1840 kg	155 mm
2.0 AT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.0 MT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.0 AT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.2 MT	4534 mm	1689 mm	1374 mm	2576 mm	1170 kg	1640 kg	155 mm
2.2 AT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.2 MT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.2 AT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm
2.0 MT	4534 mm	1689 mm	1374 mm	2576 mm	Not provided	Not provided	155 mm

Mazda 626 Cargo Space

Sedan — Mazda 626 Cargo Space

Sedan Mazda 626 Cargo Space
Modification	Trunk volume min
1.8 AT	467 l
2.0 AT	467 l
2.0 AT	467 l
2.0 AT	467 l
2.2 AT	467 l
2.2 MT	467 l
2.2 AT	467 l
1.8 MT	467 l
2.0 MT	467 l
2.0 MT	467 l
2.0 MT	467 l
2.2 MT	467 l
2.0 MT	467 l
2.0 AT	467 l

Hatchback 5-door — Mazda 626 Cargo Space

Hatchback 5-door Mazda 626 Cargo Space
Modification	Trunk volume min
1.8 MT	651 l
1.8 AT	651 l
2.0 AT	651 l
2.0 MT	651 l
2.0 MT	651 l
2.0 MT	651 l
2.0 AT	651 l
2.0 MT	651 l
2.0 AT	651 l
2.2 MT	651 l
2.2 AT	651 l
2.2 MT	651 l
2.2 AT	651 l
2.0 MT	651 l
