Catalog / Mazda / 323 Lantis / 6 generation
Mazda 323 Lantis Engines and Transmissions
Mazda 323 Lantis engine options include gasoline and diesel powertrains. Selected examples are the gasoline 1.3 MT sedan and diesel 2.0 MT three-door hatchback, both with manual transmissions, plus the gasoline 1.5 AT sedan with an automatic. These examples use front-wheel drive; a manual gives you control over gear changes, while an automatic reduces effort in stop-start traffic.
Sedan — Mazda 323 Lantis Engines and Transmissions
Sedan Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1324 cm³ 73 hp 54 kW 108 N⋅m Manual FWD 1.5 MT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 1.5 AT Gasoline 1498 cm³ 88 hp 65 kW 132 N⋅m Automatic FWD 2.0 MT Diesel 1998 cm³ 71 hp 52 kW 128 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 90 hp 66 kW 220 N⋅m Manual FWD 1.8 MT Gasoline 1840 cm³ 115 hp 84 kW 157 N⋅m Manual FWD 1.8 AT Gasoline 1840 cm³ 115 hp 84 kW 161 N⋅m Automatic FWD 1.6 AT Gasoline 1598 cm³ 105 hp 77 kW 132 N⋅m Automatic FWD 1.6 MT Gasoline 1598 cm³ 105 hp 77 kW 132 N⋅m Manual FWD
Hatchback 3-door — Mazda 323 Lantis Engines and Transmissions
Hatchback 3-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1324 cm³ 73 hp 54 kW 108 N⋅m Manual FWD 1.5 MT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 71 hp 52 kW 128 N⋅m Manual FWD
Hatchback 5-door — Mazda 323 Lantis Engines and Transmissions
Hatchback 5-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1324 cm³ 73 hp 55 kW 108 N⋅m Manual FWD 1.5 MT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 1.5 AT Gasoline 1498 cm³ 88 hp 65 kW 132 N⋅m Automatic FWD 2.0 MT Diesel 1998 cm³ 71 hp 55 kW 128 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 90 hp 70 kW 220 N⋅m Manual FWD 1.8 MT Gasoline 1840 cm³ 115 hp 84 kW 161 N⋅m Manual FWD 1.8 AT Gasoline 1840 cm³ 115 hp 84 kW 161 N⋅m Automatic FWD
Mazda 323 Lantis Dimensions
Sedan — Mazda 323 Lantis Dimensions
Sedan Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 4335 mm 1695 mm 1420 mm 2605 mm 1040 kg 1515 kg 150 mm 1.5 MT 4335 mm 1695 mm 1420 mm 2605 mm 1075 kg 1575 kg 150 mm 1.5 AT 4335 mm 1695 mm 1420 mm 2605 mm 1065 kg 1590 kg 140 mm 2.0 MT 4335 mm 1695 mm 1420 mm 2605 mm 1230 kg 1750 kg 150 mm 2.0 MT 4335 mm 1695 mm 1420 mm 2605 mm 1160 kg 1705 kg 150 mm 1.8 MT 4335 mm 1695 mm 1420 mm 2605 mm 1125 kg 1645 kg 150 mm 1.8 AT 4335 mm 1695 mm 1420 mm 2605 mm 1125 kg 1645 kg 140 mm 1.6 AT 4335 mm 1695 mm 1420 mm 2605 mm 1115 kg 1625 kg 140 mm 1.6 MT 4335 mm 1695 mm 1420 mm 2605 mm Not provided 1625 kg 140 mm
Hatchback 3-door — Mazda 323 Lantis Dimensions
Hatchback 3-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 4035 mm 1695 mm 1405 mm 2505 mm 980 kg 1510 kg 140 mm 1.5 MT 4035 mm 1695 mm 1405 mm 2505 mm 1020 kg 1585 kg 140 mm 2.0 MT 4035 mm 1695 mm 1405 mm 2505 mm 1170 kg 1690 kg 140 mm
Hatchback 5-door — Mazda 323 Lantis Dimensions
Hatchback 5-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 4340 mm 1695 mm 1355 mm 2605 mm 1115 kg 1580 kg 140 mm 1.5 MT 4340 mm 1695 mm 1355 mm 2605 mm 1115 kg 1580 kg 140 mm 1.5 AT 4340 mm 1695 mm 1355 mm 2605 mm 1115 kg 1625 kg 140 mm 2.0 MT 4340 mm 1695 mm 1355 mm 2605 mm 1150 kg 1695 kg 140 mm 2.0 MT 4340 mm 1695 mm 1355 mm 2605 mm 1150 kg 1695 kg 140 mm 1.8 MT 4340 mm 1695 mm 1355 mm 2605 mm 1165 kg 1685 kg 140 mm 1.8 AT 4340 mm 1695 mm 1355 mm 2605 mm Not provided 1625 kg 140 mm
Mazda 323 Lantis Cargo Space
Sedan — Mazda 323 Lantis Cargo Space
Hatchback 3-door — Mazda 323 Lantis Cargo Space
Hatchback 3-door Mazda 323 Lantis Cargo Space Modification Trunk volume min 1.3 MT 900 l 1.5 MT 900 l 2.0 MT 900 l
Hatchback 5-door — Mazda 323 Lantis Cargo Space
Mazda 323 Lantis Trims and Equipment
Mazda 323 Lantis trim levels distinguish equipment choices within a technical version: the gasoline, front-wheel-drive 1.6 AT sedan has configurations named GLX and LX. When comparing cars, check the equipment actually fitted and whether it works, since the trim name alone does not establish every comfort or convenience feature.
