Catalog / Mazda / 323 Lantis / 5 generation
Mazda 323 Lantis Engines and Transmissions
Mazda 323 Lantis engine choices include gasoline and diesel options. Selected front-wheel-drive Sedan examples pair gasoline power with a manual transmission in the 1.3 MT or an automatic in the 1.5 AT; the 1.7 MT combines diesel power with a manual. An automatic reduces shifting in traffic, while a manual gives you direct control over gear selection.
Sedan — Mazda 323 Lantis Engines and Transmissions
Sedan Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.3 MT Gasoline 1324 cm³ 73 hp 55 kW 108 N⋅m Manual FWD 1.5 MT Gasoline 1489 cm³ 88 hp 63 kW 132 N⋅m Manual FWD 1.5 AT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Automatic FWD 1.8 MT Gasoline 1840 cm³ 115 hp 85 kW 157 N⋅m Manual FWD 1.7 MT Diesel 1686 cm³ 82 hp 53 kW 168 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 71 hp 50 kW 128 N⋅m Manual FWD 1.8 AT Gasoline 1840 cm³ 115 hp 84 kW 157 N⋅m Automatic FWD 1.6 AT Gasoline 1597 cm³ 95 hp 69 kW Not provided Automatic FWD 1.6 MT Gasoline 1597 cm³ 95 hp 69 kW Not provided Manual FWD
Hatchback 3-door — Mazda 323 Lantis Engines and Transmissions
Hatchback 3-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.3 MT Gasoline 1324 cm³ 73 hp 54 kW 108 N⋅m Manual FWD 1.5 AT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Automatic FWD 1.5 MT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 1.8 AT Gasoline 1840 cm³ 114 hp 84 kW 157 N⋅m Automatic FWD 1.8 MT Gasoline 1840 cm³ 114 hp 84 kW 157 N⋅m Manual FWD 2.0 MT Diesel 1998 cm³ 71 hp 52 kW 128 N⋅m Manual FWD
Hatchback 5-door — Mazda 323 Lantis Engines and Transmissions
Hatchback 5-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.5 MT Gasoline 1489 cm³ 88 hp 63 kW 132 N⋅m Manual FWD 1.5 AT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Automatic FWD 2.0 MT Gasoline 1995 cm³ 144 hp 110 kW 180 N⋅m Manual FWD 2.0 AT Gasoline 1995 cm³ 144 hp 106 kW 180 N⋅m Automatic FWD 2.0 MT Diesel 1998 cm³ 71 hp 52 kW 128 N⋅m Manual FWD 1.8 MT Gasoline 1840 cm³ 114 hp 85 kW 157 N⋅m Manual FWD 1.8 AT Gasoline 1840 cm³ 114 hp 84 kW 157 N⋅m Automatic FWD
Mazda 323 Lantis Dimensions
Sedan — Mazda 323 Lantis Dimensions
Sedan Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.3 MT 4340 mm 1710 mm 1420 mm 2605 mm 1070 kg 1575 kg 140 mm 1.5 MT 4340 mm 1710 mm 1420 mm 2605 mm 1070 kg 1575 kg 140 mm 1.5 AT 4340 mm 1710 mm 1420 mm 2605 mm 1105 kg 1575 kg 140 mm 1.8 MT 4340 mm 1710 mm 1420 mm 2605 mm 1125 kg 1645 kg 140 mm 1.7 MT 4340 mm 1710 mm 1420 mm 2605 mm 1170 kg 1680 kg 140 mm 2.0 MT 4340 mm 1710 mm 1420 mm 2605 mm 1230 kg 1750 kg 140 mm 1.8 AT 4340 mm 1710 mm 1420 mm 2605 mm 1125 kg 1645 kg 140 mm 1.6 AT 4340 mm 1710 mm 1420 mm 2605 mm Not provided Not provided 140 mm 1.6 MT 4340 mm 1710 mm 1420 mm 2605 mm Not provided Not provided 140 mm
Hatchback 3-door — Mazda 323 Lantis Dimensions
Hatchback 3-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.3 MT 4035 mm 1710 mm 1405 mm 2505 mm 980 kg 1515 kg Not provided 1.5 AT 4035 mm 1710 mm 1405 mm 2505 mm 1035 kg 1575 kg Not provided 1.5 MT 4035 mm 1710 mm 1405 mm 2505 mm 1010 kg 1575 kg Not provided 1.8 AT 4035 mm 1710 mm 1405 mm 2505 mm Not provided 1625 kg 140 mm 1.8 MT 4035 mm 1710 mm 1405 mm 2505 mm 1110 kg 1625 kg 140 mm 2.0 MT 4035 mm 1710 mm 1405 mm 2505 mm 1105 kg 1750 kg Not provided
Hatchback 5-door — Mazda 323 Lantis Dimensions
Hatchback 5-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.5 MT 4245 mm 1695 mm 1355 mm 2605 mm 1115 kg 1580 kg 140 mm 1.5 AT 4245 mm 1695 mm 1355 mm 2605 mm Not provided 1580 kg 140 mm 2.0 MT 4245 mm 1695 mm 1355 mm 2605 mm 1210 kg 1740 kg 140 mm 2.0 AT 4245 mm 1695 mm 1355 mm 2605 mm 1225 kg 1740 kg 140 mm 2.0 MT 4245 mm 1695 mm 1355 mm 2605 mm 1230 kg Not provided 140 mm 1.8 MT 4245 mm 1695 mm 1355 mm 2605 mm 1115 kg 1580 kg 140 mm 1.8 AT 4245 mm 1695 mm 1355 mm 2605 mm Not provided 1685 kg 140 mm
Mazda 323 Lantis Cargo Space
Sedan — Mazda 323 Lantis Cargo Space
Hatchback 3-door — Mazda 323 Lantis Cargo Space
Hatchback 5-door — Mazda 323 Lantis Cargo Space
Mazda 323 Lantis Trims and Equipment
Among Mazda 323 Lantis trim levels, GLX is available on the 1.8 AT Sedan, which combines gasoline power, an automatic transmission and front-wheel drive. GLX identifies the equipment package, while 1.8 AT describes the powertrain. Check the individual car’s comfort and convenience features to see whether its equipment meets your needs.
Mazda 323 Lantis Trims and Equipment Modification Body Equipment
1.8 AT Sedan GLX 1.6 AT Sedan GLX 1.6 MT Sedan GLX
