Maybach S-class Specs, Engines & Dimensions (2014–2017)

Maybach S-class Engines and Transmissions

Maybach S-class engine options include the gasoline S400 3.0 AT in Sedan Long form, pairing an automatic transmission with all-wheel drive to help you pull away on slippery surfaces. The S600 6.0 AT and S600 Guard 6.0 AT Limousines use larger gasoline engines with automatic transmissions and rear-wheel drive, providing ample power for relaxed progress.

Limousine — Maybach S-class Engines and Transmissions

Limousine Maybach S-class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S600 6.0 AT	Gasoline	5980 cm³	530 hp	389 kW	830 N⋅m	Automatic	RWD
S600 Guard 6.0 AT	Gasoline	5980 cm³	530 hp	389 kW	830 N⋅m	Automatic	RWD

Sedan Long — Maybach S-class Engines and Transmissions

Sedan Long Maybach S-class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
S400 3.0 AT	Gasoline	2996 cm³	333 hp	244 kW	480 N⋅m	Automatic	AWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	334 kW	700 N⋅m	Automatic	RWD
S500 4.7 AT	Gasoline	4663 cm³	455 hp	334 kW	700 N⋅m	Automatic	AWD
S600 6.0 AT	Gasoline	5980 cm³	530 hp	389 kW	830 N⋅m	Automatic	RWD

Maybach S-class Dimensions

Limousine — Maybach S-class Dimensions

Limousine Maybach S-class Dimensions
Modification	Length	Width	Height	Wheelbase	Ground clearance, minimum
S600 6.0 AT	6499 mm	1899 mm	1598 mm	4418 mm	109 mm
S600 Guard 6.0 AT	6499 mm	1899 mm	1598 mm	4418 mm	109 mm

Sedan Long — Maybach S-class Dimensions

Sedan Long Maybach S-class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
S400 3.0 AT	5453 mm	1899 mm	1498 mm	3365 mm	2015 kg	2670 kg	109 mm
S500 4.7 AT	5453 mm	1899 mm	1498 mm	3365 mm	2220 kg	2795 kg	109 mm
S500 4.7 AT	5453 mm	1899 mm	1498 mm	3365 mm	2275 kg	2795 kg	109 mm
S600 6.0 AT	5453 mm	1899 mm	1498 mm	3365 mm	2335 kg	2815 kg	109 mm

Maybach S-class Cargo Space

Sedan Long — Maybach S-class Cargo Space

Sedan Long Maybach S-class Cargo Space
Modification	Trunk volume min
S400 3.0 AT	500 l
S500 4.7 AT	500 l
S500 4.7 AT	500 l
S600 6.0 AT	500 l
