Land Rover Range Rover 2.9 AT HSE Equipment — Third Generation

Pulling away on wet grass, traction control cuts drive to a spinning wheel so the Range Rover moves off without the tyre digging in.

3 generation · SUV 5-doors

2002–2005

2.9 AT

Diesel · Automatic · AWD

At a glance

View full specifications ↓

HSE

Report an inaccuracy ↗

Specifications

Jump to a section

Performance & powertrain

Top speed
?

The highest speed a vehicle can sustain under manufacturer test conditions. Some cars are electronically limited below their mechanical potential. Glossary entry

179 km/h
Engine type
Diesel
Transmission
Automatic
Type of boost
?

A turbocharger or supercharger compresses the air entering the engine so a smaller engine can produce more power. Naturally aspirated engines draw air without a compressor. Glossary entry

Turbo
Type of drive
?

Which wheels receive power: front-wheel drive, rear-wheel drive or all-wheel drive. All-wheel drive can send power to every wheel for extra traction. Glossary entry

AWD
Bore and stroke
?

The diameter of a cylinder (bore) and the distance the piston travels inside it (stroke). Together they determine the displacement of the engine. Glossary entry

84 × 88 mm
Engine capacity
?

The total volume swept by all pistons inside the cylinders, usually stated in cubic centimetres or litres. Larger displacement often means more power but higher consumption. Glossary entry

2926 cm³
Engine location
Front, longitudinal
Number of gears
?

How many fixed forward ratios a gearbox offers. More gears can improve economy and refinement; continuously variable transmissions have no fixed steps. Glossary entry

5
Maximum power
?

A unit of engine or motor output. One metric horsepower is about 0.735 kilowatts. Peak power is normally reached at high engine speed. Glossary entry

177 hp
Maximum power, kw
?

A unit of engine or motor output. One metric horsepower is about 0.735 kilowatts. Peak power is normally reached at high engine speed. Glossary entry

130 kW
Compression ratio
?

The ratio between the largest and smallest volume of a cylinder as the piston moves. Higher ratios improve efficiency but may require higher-octane fuel. Glossary entry

18.1
Maximum power rpm
4000 rpm
Maximum torque N⋅m
390 N⋅m
Maximum torque rpm
2000 rpm
Acceleration to 100
?

The time a vehicle needs to reach 100 km/h from a standstill, a common shorthand for overall performance. Glossary entry

13.6 s
Engine power system
Not provided
Number of cylinders
6
Valves per cylinder
?

The number of intake and exhaust valves in each cylinder. Four valves per cylinder is common and helps the engine breathe at higher speeds. Glossary entry

4
Cylinder arrangement
Inline
Maximum power ICE
Not provided
Maximum power ICE
Not provided

Energy & emissions

ECO class
Not provided
Battery power
Not provided
Fuel grade
Diesel
Mild Hybrid
?

A car with a small electric motor and battery that assist the combustion engine and recover braking energy but cannot drive on electricity alone. Glossary entry

Not provided
Battery type
Not provided
CO2 emissions
?

The amount of carbon dioxide released per kilometre under a standardised test. Lower figures usually go hand in hand with lower fuel consumption. Glossary entry

Not provided
Full charge home
Not provided
Power consumption
Not provided
Fuel tank capacity
100 l
Full public charging time
Not provided
Driving range, maximum
?

The distance an electric or plug-in vehicle can travel on a full charge under a stated test cycle. Temperature, speed and load change the real result. Glossary entry

Not provided
Driving range, minimum
?

The distance an electric or plug-in vehicle can travel on a full charge under a stated test cycle. Temperature, speed and load change the real result. Glossary entry

Not provided
Fuel consumption city
Not provided
Average consumption
Not provided
Fuel consumption highway
Not provided

Dimensions & body

Doors number
5
Number of seats
5
Width
1956 mm
Height
1863 mm
Length
4950 mm
Body type
SUV 5-doors
Wheelbase
?

The distance between the centres of the front and rear wheels. A longer wheelbase usually gives more cabin space and a calmer ride; a shorter one helps agility and parking. Glossary entry

2880 mm
U-turn diameter
Not provided
Depth of the ford to be crossed
Not provided
Body style
SUV
Rear track width
?

The distance between the centres of the two wheels on the same axle. A wider track generally improves stability in corners. Glossary entry

1626 mm
Trunk volume max
1755 l
Trunk volume min
535 l
Front track width
?

The distance between the centres of the two wheels on the same axle. A wider track generally improves stability in corners. Glossary entry

1629 mm
Max weight
3050 kg
Curb weight
?

The weight of the vehicle with all standard equipment and fluids but without passengers or cargo. Glossary entry

2435 kg
Ground clearance, maximum
?

The gap between the lowest point of the underbody and the road. More clearance helps on rough roads and steep driveway ramps. Glossary entry

Not provided
Ground clearance, minimum
?

The gap between the lowest point of the underbody and the road. More clearance helps on rough roads and steep driveway ramps. Glossary entry

230 mm

Identity & configuration

Body code
L322
Vehicle class
J
Body designation
L322
Right-hand drive
No

Additional specifications

Stop
2005-01-31
Start
2002-02-01
Wheel size
Not provided
Rear brakes
Disc
Front brakes
Ventilated disc
Rear suspension
Independent, pneumatic
Front suspension
Independent, pneumatic

Trim equipment

Dimensions & body

Number of seats
5

Additional specifications

Driver Assistance Systems
Anti-lock braking system (ABS), Electronic stability program (ESP), Emergency brake assist (BAS, EBD, EBA), Automatic slip regulation (ASR)
Stop
2005-01-31
View
Fog lamp, Light sensor, Rain sensor
Start
2002-02-01
Airbags
Driver's airbag, Passenger airbag, Side front airbags, Window airbags (curtains), Driver's knee airbag
Isofix
Isofix for the back row
Material
Alloy
Comfort
On-board computer, Power folding mirrors, Power mirrors, Multifunction steering wheel
Interior
Folding rear seat, Sunroof, Power window
Headlights
Xenon / Bi-Xenon
Sound
Audio system
Diameter
R18 ″
Multimedia
Bluetooth
Cruise control
Cruise control
Parking assist system
Front parking sensors, Rear parking sensors
Power steering
Power steering
Air conditioner
Single-zone climate control
Anti theft system
Keyless central locking, Immobilizer
Seat trim
Genuine leather seats

Not provided means the source has no value. Zero remains zero. Units are shown as supplied; range test cycles are only stated when known.

Fuel cost calculator

Estimates use only the figures you enter, in your own currency. No live fuel prices or emissions data are used.

Units

Enable JavaScript to calculate estimates.

Comfort and Convenience

With single-zone climate control, one temperature dial sets the target for the whole cabin, and the on-board computer display confirms the value the system is working toward.

Safety and Driver Assistance

Brake assist boosts pressure once the pedal is pushed quickly, but braking only starts after the driver reacts. That thinking time still has to fit inside the gap ahead.

Multimedia and Connectivity

Pairing a phone over Bluetooth once lets the audio system reconnect automatically on later drives, so the handset stays in a pocket while tracks play through the speakers.
