Kia Picanto Specs, Engines & Dimensions (2011–2015)

Kia Picanto Engines and Transmissions

The Kia Picanto engine choices in this generation are gasoline units with a front-wheel-drive drivetrain. Selected Mini 5-doors examples include 1.0 AT, 1.0 MT, and 1.3 MT, so you can match an automatic or manual transmission to city traffic. They illustrate the powertrain spread, not every version.

Mini 5-doors — Kia Picanto Engines and Transmissions

Mini 5-doors Kia Picanto Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 AT	Gasoline	1248 cm³	85 hp	63 kW	121 N⋅m	Automatic	FWD
1.0 AT	Gasoline	998 cm³	69 hp	51 kW	95 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1248 cm³	85 hp	63 kW	121 N⋅m	Manual	FWD
1.3 AT	Gasoline	1248 cm³	85 hp	63 kW	121 N⋅m	Automatic	FWD
1.0 MT	Gasoline	998 cm³	69 hp	51 kW	95 N⋅m	Manual	FWD

Mini 3-doors — Kia Picanto Engines and Transmissions

Mini 3-doors Kia Picanto Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 AT	Gasoline	1248 cm³	85 hp	63 kW	121 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1248 cm³	85 hp	63 kW	121 N⋅m	Manual	FWD

Kia Picanto Dimensions

Mini 5-doors — Kia Picanto Dimensions

Mini 5-doors Kia Picanto Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
1.3 AT	3595 mm	1595 mm	1480 mm	2385 mm	870 kg	1365 kg	152 mm	Not provided
1.0 AT	3595 mm	1595 mm	1480 mm	2385 mm	840 kg	1310 kg	152 mm	Not provided
1.3 MT	3595 mm	1595 mm	1480 mm	2385 mm	870 kg	Not provided	142 mm	Not provided
1.3 AT	3595 mm	1595 mm	1480 mm	2385 mm	870 kg	1365 kg	142 mm	152 mm
1.0 MT	3595 mm	1595 mm	1480 mm	2385 mm	840 kg	1310 kg	152 mm	Not provided

Mini 3-doors — Kia Picanto Dimensions

Mini 3-doors Kia Picanto Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
1.3 AT	3595 mm	1595 mm	1480 mm	2385 mm	870 kg	1365 kg	142 mm	152 mm
1.3 MT	3595 mm	1595 mm	1480 mm	2385 mm	870 kg	Not provided	142 mm	Not provided

Kia Picanto Cargo Space

Mini 5-doors — Kia Picanto Cargo Space

Mini 5-doors Kia Picanto Cargo Space
Modification	Trunk volume min	Trunk volume max
1.3 AT	200 l	870 l
1.0 AT	200 l	870 l
1.3 MT	200 l	870 l
1.3 AT	200 l	870 l
1.0 MT	200 l	870 l

Mini 3-doors — Kia Picanto Cargo Space

Mini 3-doors Kia Picanto Cargo Space
Modification	Trunk volume min
1.3 AT	292 l
1.3 MT	292 l

Kia Picanto Trims and Equipment

On the 1.0 MT Mini 5-doors, Kia Picanto trim levels include Classic and Comfort. Those equipment names sit on the same gasoline manual, front-wheel-drive version, so you choose cabin extras rather than a different powertrain. Treat that pairing as an example for this generation, not a rule for every body.

Kia Picanto Trims and Equipment
Modification	Body	Equipment
1.3 AT	Mini 5-doors	Luxe
1.3 AT	Mini 5-doors	Prestige
1.0 MT	Mini 5-doors	Classic
1.0 MT	Mini 5-doors	Comfort
1.0 MT	Mini 5-doors	EX
1.0 MT	Mini 5-doors	LX
1.3 MT	Mini 3-doors	Sport
