Catalog / Isuzu / Wizard / 2 generation
Isuzu Wizard Engines and Transmissions
You can pick an Isuzu Wizard engine for diesel or gasoline use. The 3.0 AT is a diesel automatic with all-wheel drive, and the 3.2 MT is a gasoline manual with the same drivetrain. A 3.2 AT gasoline automatic uses rear-wheel drive instead—selected powertrain examples, not every transmission.
SUV 5-doors — Isuzu Wizard Engines and Transmissions
SUV 5-doors Isuzu Wizard Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
3.0 AT Diesel 2999 cm³ 145 hp 107 kW 294 N⋅m Automatic AWD 3.0 MT Diesel 2999 cm³ 145 hp 107 kW 294 N⋅m Manual AWD 3.2 AT Gasoline 3165 cm³ 215 hp 158 kW 294 N⋅m Automatic RWD 3.2 AT Gasoline 3165 cm³ 215 hp 158 kW 294 N⋅m Automatic AWD 3.2 MT Gasoline 3165 cm³ 215 hp 158 kW 284 N⋅m Manual AWD
Isuzu Wizard Dimensions
SUV 5-doors — Isuzu Wizard Dimensions
SUV 5-doors Isuzu Wizard Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
3.0 AT 4250 mm 1815 mm 1135 mm 2460 mm 1770 kg 205 mm 3.0 MT 4250 mm 1815 mm 1135 mm 2460 mm 1890 kg 205 mm 3.2 AT 4250 mm 1815 mm 1135 mm 2460 mm 1700 kg 180 mm 3.2 AT 4250 mm 1815 mm 1135 mm 2460 mm 1740 kg 180 mm 3.2 MT 4250 mm 1815 mm 1135 mm 2460 mm 1890 kg 205 mm
