Hyundai Santa Fe Engines and Transmissions
You can choose a Hyundai Santa Fe engine as a 2.0 diesel or a 3.0 gasoline unit. The 2.0 MT pairs a manual transmission with front- or all-wheel drive, while the 3.0 AT uses an automatic and all-wheel drivetrain. These powertrain examples are typical of the generation, not every version.
SUV 5-doors — Hyundai Santa Fe Engines and Transmissions
SUV 5-doors Hyundai Santa Fe Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.2 AT Diesel 2199 cm³ 200 hp 147 kW 440 N⋅m Automatic AWD 2.0 MT Diesel 1995 cm³ 150 hp 110 kW 400 N⋅m Manual FWD 2.0 MT Diesel 1995 cm³ 150 hp 110 kW 400 N⋅m Manual AWD 2.2 MT Diesel 2199 cm³ 200 hp 147 kW 440 N⋅m Manual FWD 2.2 MT Diesel 2199 cm³ 200 hp 147 kW 440 N⋅m Manual AWD 2.2 AT Diesel 2199 cm³ 200 hp 147 kW 440 N⋅m Automatic FWD 2.4 AT Gasoline 2359 cm³ 171 hp 126 kW 225 N⋅m Automatic AWD 2.4 MT Gasoline 2359 cm³ 171 hp 126 kW 225 N⋅m Manual AWD 2.4 MT Gasoline 2359 cm³ 188 hp 138 kW 241 N⋅m Manual FWD 2.4 MT Gasoline 2359 cm³ 188 hp 138 kW 241 N⋅m Manual AWD 2.4 AT Gasoline 2359 cm³ 188 hp 138 kW 241 N⋅m Automatic FWD 2.4 AT Gasoline 2359 cm³ 188 hp 138 kW 241 N⋅m Automatic AWD 2.2 AT Diesel 2199 cm³ 200 hp 149 kW 440 N⋅m Automatic AWD 3.0 AT Gasoline 2999 cm³ 249 hp 183 kW 306 N⋅m Automatic AWD 3.3 AT Gasoline 3342 cm³ 294 hp 216 kW 342 N⋅m Automatic FWD 3.3 AT Gasoline 3342 cm³ 294 hp 216 kW 342 N⋅m Automatic AWD 2.4 AT Gasoline 2359 cm³ 192 hp 141 kW 242 N⋅m Automatic AWD 2.2 AT Diesel 2199 cm³ 197 hp 144 kW 436 N⋅m Automatic AWD
Hyundai Santa Fe Dimensions
SUV 5-doors — Hyundai Santa Fe Dimensions
SUV 5-doors Hyundai Santa Fe Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.2 AT 4690 mm 1880 mm 1680 mm 2700 mm 1907 kg 2510 kg 185 mm 2.0 MT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.0 MT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.2 MT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.2 MT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.2 AT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.4 AT 4690 mm 1880 mm 1680 mm 2700 mm 1793 kg 2510 kg 185 mm 2.4 MT 4690 mm 1880 mm 1680 mm 2700 mm 1773 kg 2510 kg 185 mm 2.4 MT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.4 MT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.4 AT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.4 AT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.2 AT 4690 mm 1880 mm 1680 mm 2700 mm 1991 kg 2630 kg 180 mm 3.0 AT 4690 mm 1880 mm 1680 mm 2700 mm 1937 kg 2600 kg 180 mm 3.3 AT 4690 mm 1880 mm 1680 mm 2700 mm 1813 kg 2500 kg 180 mm 3.3 AT 4690 mm 1880 mm 1680 mm 2700 mm 1895 kg 2550 kg 180 mm 2.4 AT 4690 mm 1880 mm 1680 mm 2700 mm Not provided Not provided 185 mm 2.2 AT 4690 mm 1880 mm 1680 mm 2700 mm 1882 kg 2510 kg 185 mm
Hyundai Santa Fe Cargo Space
SUV 5-doors — Hyundai Santa Fe Cargo Space
Hyundai Santa Fe Trims and Equipment
