Hyundai Palisade Specs, Engines & Dimensions (2018–2023)

Hyundai Palisade Engines and Transmissions

Each Hyundai Palisade engine pairs with an automatic transmission, so the choice really comes down to fuel and drivetrain. The 2.2 diesel favours economy and relaxed torque, offered with front- or all-wheel drive, while the 3.5 gasoline version with all-wheel drive delivers smoother, quieter acceleration.

SUV 5-doors — Hyundai Palisade Engines and Transmissions

SUV 5-doors Hyundai Palisade Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.2 AT	Diesel	2199 cm³	200 hp	147 kW	441 N⋅m	Automatic	FWD
2.2 AT	Diesel	2199 cm³	200 hp	147 kW	441 N⋅m	Automatic	AWD
3.5 AT	Gasoline	3470 cm³	277 hp	204 kW	335 N⋅m	Automatic	FWD
3.5 AT	Gasoline	3470 cm³	277 hp	204 kW	335 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	291 hp	217 kW	355 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	291 hp	217 kW	355 N⋅m	Automatic	FWD
3.8 AT	Gasoline	3778 cm³	291 hp	217 kW	355 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	291 hp	217 kW	355 N⋅m	Automatic	FWD

Hyundai Palisade Dimensions

SUV 5-doors — Hyundai Palisade Dimensions

SUV 5-doors Hyundai Palisade Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.2 AT	4980 mm	1975 mm	1750 mm	2900 mm	1870 kg	2610 kg	200 mm
2.2 AT	4980 mm	1975 mm	1750 mm	2900 mm	1942 kg	2670 kg	200 mm
3.5 AT	4980 mm	1975 mm	1750 mm	2900 mm	1820 kg	2560 kg	200 mm
3.5 AT	4980 mm	1975 mm	1750 mm	2900 mm	1892 kg	2610 kg	200 mm
3.8 AT	4980 mm	1975 mm	1750 mm	2900 mm	1992 kg	2665 kg	200 mm
3.8 AT	4980 mm	1975 mm	1750 mm	2900 mm	1920 kg	2602 kg	200 mm
3.8 AT	4980 mm	1975 mm	1750 mm	2900 mm	1992 kg	2665 kg	203 mm
3.8 AT	4980 mm	1975 mm	1750 mm	2900 mm	1920 kg	2602 kg	203 mm

Hyundai Palisade Cargo Space

SUV 5-doors — Hyundai Palisade Cargo Space

SUV 5-doors Hyundai Palisade Cargo Space
Modification	Trunk volume min	Trunk volume max
2.2 AT	510 l	2000 l
2.2 AT	510 l	2000 l
3.5 AT	510 l	2000 l
3.5 AT	510 l	2000 l
3.8 AT	510 l	2000 l
3.8 AT	510 l	2000 l
3.8 AT	510 l	2000 l
3.8 AT	510 l	2000 l

Hyundai Palisade Trims and Equipment

Hyundai Palisade Trims and Equipment
Modification	Body	Equipment
3.8 AT	SUV 5-doors	Luxury
3.8 AT	SUV 5-doors	Limited
3.8 AT	SUV 5-doors	Premium
