Honda Shuttle Specs, Engines & Dimensions (1995–2000)

Honda Shuttle Engines and Transmissions

Every Honda Shuttle engine here is gasoline and paired with an automatic transmission, which suits stop-start city driving and loaded family trips. The 2.2 AT came with front-wheel or all-wheel drive, while the 2.3 AT example is all-wheel drive; the larger displacement gives easier pulling when the van is full.

Compact Van — Honda Shuttle Engines and Transmissions

Compact Van Honda Shuttle Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.2 AT	Gasoline	2155 cm³	150 hp	110 kW	198 N⋅m	Automatic	AWD
2.3 AT	Gasoline	2254 cm³	150 hp	110 kW	200 N⋅m	Automatic	AWD
2.2 AT	Gasoline	2155 cm³	150 hp	110 kW	198 N⋅m	Automatic	FWD
2.3 AT	Gasoline	2253 cm³	150 hp	110 kW	206 N⋅m	Automatic	FWD

Honda Shuttle Dimensions

Compact Van — Honda Shuttle Dimensions

Compact Van Honda Shuttle Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.2 AT	4770 mm	1795 mm	1630 mm	2830 mm	Not provided	Not provided	155 mm
2.3 AT	4770 mm	1795 mm	1630 mm	2830 mm	1565 kg	2200 kg	160 mm
2.2 AT	4770 mm	1795 mm	1630 mm	2830 mm	Not provided	Not provided	155 mm
2.3 AT	4770 mm	1795 mm	1630 mm	2830 mm	1565 kg	2200 kg	160 mm

Honda Shuttle Cargo Space

Compact Van — Honda Shuttle Cargo Space

Compact Van Honda Shuttle Cargo Space
Modification	Trunk volume min	Trunk volume max
2.2 AT	290 l	1237 l
2.3 AT	290 l	1237 l
2.2 AT	290 l	1237 l
2.3 AT	290 l	1237 l
