Honda S-MX Specs, Engines & Dimensions (1996–2002)

Honda S-MX Engines and Transmissions

Every Honda S-MX engine in this generation runs on gasoline, so the powertrain stays simple for commuting and family trips. You pair that petrol unit with the available transmission, and the drivetrain is set up for easy urban driving rather than heavy work.

Compact Van — Honda S-MX Engines and Transmissions

Compact Van Honda S-MX Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 AT	Gasoline	1973 cm³	131 hp	96 kW	186 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1973 cm³	131 hp	96 kW	186 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1973 cm³	140 hp	103 kW	186 N⋅m	Automatic	AWD
2.0 AT	Gasoline	1973 cm³	140 hp	103 kW	186 N⋅m	Automatic	FWD

Honda S-MX Dimensions

Compact Van — Honda S-MX Dimensions

Compact Van Honda S-MX Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 AT	3950 mm	1695 mm	1750 mm	2500 mm	1330 kg	Not provided	140 mm
2.0 AT	3950 mm	1695 mm	1750 mm	2500 mm	1400 kg	Not provided	140 mm
2.0 AT	3950 mm	1695 mm	1750 mm	2500 mm	1420 kg	1695 kg	140 mm
2.0 AT	3950 mm	1695 mm	1750 mm	2500 mm	1370 kg	1645 kg	140 mm

Honda S-MX Cargo Space

Compact Van — Honda S-MX Cargo Space

Compact Van Honda S-MX Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 AT	340 l	920 l
2.0 AT	340 l	920 l
2.0 AT	340 l	920 l
2.0 AT	340 l	920 l
