Catalog / Ford / Mondeo / 5 generation, restyling
Ford Mondeo Engines and Transmissions
Ford Mondeo engine choices on this restyling include a 2.0 hybrid CVT and a 2.0 diesel automatic. You get front-wheel drive on the hybrid sedan and estate, while the diesel estate automatic can drive all four wheels. Treat these as examples of the powertrain mix, not every transmission or drivetrain.
Sedan — Ford Mondeo Engines and Transmissions
Sedan Ford Mondeo Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 CVT Hybrid 1999 cm³ 187 hp 137 kW 300 N⋅m Variable FWD
Estate 5-door — Ford Mondeo Engines and Transmissions
Estate 5-door Ford Mondeo Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Diesel 1995 cm³ 120 hp 88 kW 340 N⋅m Manual FWD 2.0 MT Diesel 1995 cm³ 150 hp 110 kW 370 N⋅m Manual FWD 2.0 AT Diesel 1995 cm³ 150 hp 110 kW 370 N⋅m Automatic FWD 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic FWD 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic AWD 2.0 CVT Hybrid 1999 cm³ 187 hp 137 kW 300 N⋅m Variable FWD
Liftback — Ford Mondeo Engines and Transmissions
Liftback Ford Mondeo Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Diesel 1995 cm³ 120 hp 88 kW 340 N⋅m Manual FWD 2.0 MT Diesel 1995 cm³ 150 hp 110 kW 370 N⋅m Manual FWD 2.0 AT Diesel 1995 cm³ 150 hp 110 kW 370 N⋅m Automatic FWD 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic FWD 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic AWD
Ford Mondeo Dimensions
Sedan — Ford Mondeo Dimensions
Sedan Ford Mondeo Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 CVT 4871 mm 1852 mm 1482 mm 2850 mm 1696 kg 2250 kg 128 mm
Estate 5-door — Ford Mondeo Dimensions
Estate 5-door Ford Mondeo Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4869 mm 1852 mm 1501 mm 2850 mm 1720 kg 2330 kg 128 mm 2.0 MT 4869 mm 1852 mm 1501 mm 2850 mm 1728 kg 2330 kg 128 mm 2.0 AT 4869 mm 1852 mm 1501 mm 2850 mm 1748 kg 2330 kg 128 mm 2.0 AT 4869 mm 1852 mm 1501 mm 2850 mm 1752 kg 2330 kg 128 mm 2.0 AT 4869 mm 1852 mm 1501 mm 2850 mm 1826 kg 2365 kg 128 mm 2.0 CVT 4869 mm 1852 mm 1501 mm 2850 mm 1716 kg 2260 kg 128 mm
Liftback — Ford Mondeo Dimensions
Liftback Ford Mondeo Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4871 mm 1852 mm 1482 mm 2850 mm 1707 kg 2310 kg 128 mm 2.0 MT 4871 mm 1852 mm 1482 mm 2850 mm 1715 kg 2310 kg 128 mm 2.0 AT 4871 mm 1852 mm 1482 mm 2850 mm 1735 kg 2330 kg 128 mm 2.0 AT 4871 mm 1852 mm 1482 mm 2850 mm 1739 kg 2320 kg 128 mm 2.0 AT 4871 mm 1852 mm 1482 mm 2850 mm 1812 kg 2330 kg 128 mm
Ford Mondeo Cargo Space
Sedan — Ford Mondeo Cargo Space
Sedan Ford Mondeo Cargo Space Modification Trunk volume min 2.0 CVT 383 l
Estate 5-door — Ford Mondeo Cargo Space
Estate 5-door Ford Mondeo Cargo Space Modification Trunk volume min Trunk volume max 2.0 MT 730 l 1605 l 2.0 MT 730 l 1605 l 2.0 AT 730 l 1605 l 2.0 AT 730 l 1605 l 2.0 AT 730 l 1605 l 2.0 CVT 730 l 1605 l
Liftback — Ford Mondeo Cargo Space
Liftback Ford Mondeo Cargo Space Modification Trunk volume min Trunk volume max 2.0 MT 645 l 1437 l 2.0 MT 645 l 1437 l 2.0 AT 645 l 1437 l 2.0 AT 645 l 1437 l 2.0 AT 645 l 1437 l
