Excalibur Series IV Specs, Engines & Dimensions (1980–1985)

Excalibur Series IV Engines and Transmissions

An Excalibur Series IV engine is a gasoline powertrain built for easy touring, not racetrack figures. In the Roadster and Phaeton, that drivetrain and its transmission pairing favor a relaxed cruise over hard acceleration. Exact outputs still depend on the configuration you choose.

Roadster — Excalibur Series IV Engines and Transmissions

Roadster Excalibur Series IV Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
5.0 AT	Gasoline	5001 cm³	157 hp	115 kW	326 N⋅m	Automatic	RWD
5.0 AT	Gasoline	5001 cm³	157 hp	115 kW	326 N⋅m	Automatic	RWD
5.0 AT	Gasoline	5001 cm³	198 hp	146 kW	400 N⋅m	Automatic	RWD

Phaeton — Excalibur Series IV Engines and Transmissions

Phaeton Excalibur Series IV Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
5.0 AT	Gasoline	5001 cm³	157 hp	115 kW	326 N⋅m	Automatic	RWD
5.0 AT	Gasoline	5001 cm³	157 hp	115 kW	326 N⋅m	Automatic	RWD
5.0 AT	Gasoline	5001 cm³	157 hp	115 kW	326 N⋅m	Automatic	RWD

Excalibur Series IV Dimensions

Roadster — Excalibur Series IV Dimensions

Roadster Excalibur Series IV Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
5.0 AT	5131 mm	1905 mm	1499 mm	3175 mm	1990 kg	Not provided	178 mm
5.0 AT	5131 mm	1905 mm	1499 mm	3175 mm	2040 kg	Not provided	178 mm
5.0 AT	5131 mm	1905 mm	1499 mm	3175 mm	2110 kg	2750 kg	Not provided

Phaeton — Excalibur Series IV Dimensions

Phaeton Excalibur Series IV Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
5.0 AT	5258 mm	1905 mm	1499 mm	3175 mm	1990 kg	178 mm
5.0 AT	5258 mm	1905 mm	1499 mm	3175 mm	2040 kg	178 mm
5.0 AT	5258 mm	1905 mm	1499 mm	3175 mm	1996 kg	178 mm
