Chrysler Grand Voyager Specs, Engines & Dimensions (1995–2000)

Chrysler Grand Voyager Engines and Transmissions

Choosing a Chrysler Grand Voyager engine mostly means balancing running costs against effort. The 2.4 MT is a straightforward front-wheel-drive petrol with a manual gearbox, while the 2.5 MT diesel favours economy on long trips. The 3.0 AT pairs an automatic transmission with all-wheel drive for relaxed, surer-footed driving.

Minivan — Chrysler Grand Voyager Engines and Transmissions

Minivan Chrysler Grand Voyager Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.4 MT	Gasoline	2429 cm³	150 hp	110 kW	229 N⋅m	Manual	FWD
2.4 AT	Gasoline	2429 cm³	150 hp	110 kW	229 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	152 hp	112 kW	239 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	152 hp	112 kW	239 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	166 hp	122 kW	308 N⋅m	Automatic	FWD
3.8 AT	Gasoline	3778 cm³	166 hp	122 kW	308 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	180 hp	132 kW	325 N⋅m	Automatic	AWD
3.8 AT	Gasoline	3778 cm³	180 hp	132 kW	325 N⋅m	Automatic	FWD
2.5 MT	Diesel	2499 cm³	116 hp	85 kW	280 N⋅m	Manual	FWD
2.0 AT	Gasoline	1996 cm³	133 hp	98 kW	175 N⋅m	Automatic	FWD
3.3 AT	Gasoline	3301 cm³	158 hp	116 kW	275 N⋅m	Automatic	FWD

Chrysler Grand Voyager Dimensions

Minivan — Chrysler Grand Voyager Dimensions

Minivan Chrysler Grand Voyager Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.4 MT	4730 mm	1950 mm	1800 mm	2878 mm	1720 kg	2415 kg	130 mm
2.4 AT	4730 mm	1950 mm	1800 mm	2878 mm	1780 kg	2435 kg	130 mm
3.0 AT	4730 mm	1950 mm	1800 mm	2878 mm	1669 kg	2454 kg	140 mm
3.0 AT	4730 mm	1950 mm	1800 mm	2878 mm	Not provided	Not provided	140 mm
3.8 AT	4730 mm	1950 mm	1800 mm	2878 mm	Not provided	Not provided	130 mm
3.8 AT	4730 mm	1950 mm	1800 mm	2878 mm	2000 kg	2600 kg	130 mm
3.8 AT	4730 mm	1950 mm	1800 mm	2878 mm	2035 kg	2605 kg	130 mm
3.8 AT	4730 mm	1950 mm	1800 mm	2878 mm	Not provided	Not provided	130 mm
2.5 MT	4730 mm	1950 mm	1800 mm	2878 mm	1810 kg	2505 kg	130 mm
2.0 AT	4730 mm	1950 mm	1800 mm	2878 mm	1705 kg	2385 kg	130 mm
3.3 AT	4730 mm	1950 mm	1800 mm	2878 mm	1875 kg	2530 kg	130 mm

Chrysler Grand Voyager Cargo Space

Minivan — Chrysler Grand Voyager Cargo Space

Minivan Chrysler Grand Voyager Cargo Space
Modification	Trunk volume min	Trunk volume max
2.4 MT	450 l	4140 l
2.4 AT	450 l	4140 l
3.0 AT	450 l	4140 l
3.0 AT	450 l	4140 l
3.8 AT	450 l	4140 l
3.8 AT	450 l	4140 l
3.8 AT	450 l	4140 l
3.8 AT	450 l	4140 l
2.5 MT	450 l	4140 l
2.0 AT	450 l	4140 l
3.3 AT	450 l	4140 l

Chrysler Grand Voyager Specs, Engines & Dimensions (1995–2000) — Third Generation

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager

Chrysler Grand Voyager Engines and Transmissions

Minivan — Chrysler Grand Voyager Engines and Transmissions

Chrysler Grand Voyager Dimensions

Minivan — Chrysler Grand Voyager Dimensions

Chrysler Grand Voyager Cargo Space

Minivan — Chrysler Grand Voyager Cargo Space
