Catalog / Cadillac / CTS-V / 2 generation
Cadillac CTS-V Engines and Transmissions
The Cadillac CTS-V engine is a supercharged gasoline V8, giving you strong pulling power for overtaking. Selected powertrains include the rear-wheel-drive 6.2 MT Coupe and manual or automatic Estate 5-door versions. The manual transmission adds involvement through clutch control and gear selection, while the automatic makes stop-start traffic easier to manage.
Coupe — Cadillac CTS-V Engines and Transmissions
Coupe Cadillac CTS-V Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 6.2 AT Gasoline 6162 cm³ 564 hp 415 kW 747 N⋅m Automatic RWD 6.2 MT Gasoline 6162 cm³ 564 hp 415 kW 747 N⋅m Manual RWD 6.2 AT Gasoline 6162 cm³ 556 hp 408 kW 747 N⋅m Automatic RWD
Estate 5-door — Cadillac CTS-V Engines and Transmissions
Estate 5-door Cadillac CTS-V Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 6.2 MT Gasoline 6162 cm³ 564 hp 415 kW 747 N⋅m Manual RWD 6.2 AT Gasoline 6162 cm³ 564 hp 415 kW 747 N⋅m Automatic RWD
Sedan — Cadillac CTS-V Engines and Transmissions
Sedan Cadillac CTS-V Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 6.2 MT Gasoline 6162 cm³ 564 hp 415 kW 747 N⋅m Manual RWD 6.2 AT Gasoline 6162 cm³ 564 hp 415 kW 747 N⋅m Automatic RWD 6.2 AT Gasoline 6162 cm³ 556 hp 408 kW 747 N⋅m Automatic RWD
Cadillac CTS-V Dimensions
Coupe — Cadillac CTS-V Dimensions
Coupe Cadillac CTS-V Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 6.2 AT 4789 mm 1883 mm 1422 mm 2880 mm 2040 kg 150 mm 6.2 MT 4789 mm 1883 mm 1422 mm 2880 mm 2040 kg 150 mm 6.2 AT 4789 mm 1883 mm 1422 mm 2880 mm 2040 kg 150 mm
Estate 5-door — Cadillac CTS-V Dimensions
Estate 5-door Cadillac CTS-V Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 6.2 MT 4877 mm 1841 mm 1473 mm 2880 mm 1995 kg 150 mm 6.2 AT 4877 mm 1841 mm 1473 mm 2880 mm 2010 kg 150 mm
Sedan — Cadillac CTS-V Dimensions
Sedan Cadillac CTS-V Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 6.2 MT 4858 mm 1842 mm 1455 mm 2880 mm 1914 kg 2500 kg Not provided 6.2 AT 4858 mm 1842 mm 1455 mm 2880 mm 2040 kg Not provided 150 mm 6.2 AT 4858 mm 1842 mm 1455 mm 2880 mm 2040 kg Not provided 150 mm
Cadillac CTS-V Cargo Space
Coupe — Cadillac CTS-V Cargo Space
Coupe Cadillac CTS-V Cargo Space Modification Trunk volume min 6.2 AT 298 l 6.2 MT 298 l 6.2 AT 298 l
Estate 5-door — Cadillac CTS-V Cargo Space
Estate 5-door Cadillac CTS-V Cargo Space Modification Trunk volume min 6.2 MT 1642 l 6.2 AT 1642 l
Sedan — Cadillac CTS-V Cargo Space
Sedan Cadillac CTS-V Cargo Space Modification Trunk volume min 6.2 MT 385 l 6.2 AT 385 l 6.2 AT 385 l
Cadillac CTS-V Trims and Equipment
Cadillac CTS-V Trims and Equipment Modification Body Equipment 6.2 AT Coupe Sport 6.2 AT Sedan Sport
