BMW X4 Engines and Transmissions
Your BMW X4 engine choice should reflect how you drive. Selected examples include the automatic diesel 35d 3.0 AT xDrive for relaxed overtaking, the gasoline M40i 3.0 AT xDrive for a stronger performance focus, and the diesel 20d 2.0 MT xDrive for manual control. All three have all-wheel drive; an automatic reduces shifting effort in traffic.
SUV 5-doors — BMW X4 Engines and Transmissions
| Modification | Engine type | Engine capacity | Maximum power | Maximum power, kw | Maximum torque N⋅m | Transmission | Type of drive |
|---|---|---|---|---|---|---|---|
| 30d 3.0 AT xDrive | Diesel | 2993 cm³ | 249 hp | 183 kW | 560 N⋅m | Automatic | AWD |
| 35d 3.0 AT xDrive | Diesel | 2993 cm³ | 313 hp | 230 kW | 630 N⋅m | Automatic | AWD |
| M40i 3.0 AT xDrive | Gasoline | 2979 cm³ | 360 hp | 265 kW | 465 N⋅m | Automatic | AWD |
| 20d 2.0 MT xDrive | Diesel | 1995 cm³ | 190 hp | 140 kW | 400 N⋅m | Manual | AWD |
| 20d 2.0 AT xDrive | Diesel | 1995 cm³ | 190 hp | 140 kW | 400 N⋅m | Automatic | AWD |
| 30d 3.0 AT xDrive | Diesel | 2993 cm³ | 258 hp | 190 kW | 560 N⋅m | Automatic | AWD |
| 20i 2.0 AT xDrive | Gasoline | 1997 cm³ | 184 hp | 135 kW | 270 N⋅m | Automatic | AWD |
| 28i 2.0 AT xDrive | Gasoline | 1997 cm³ | 245 hp | 180 kW | 350 N⋅m | Automatic | AWD |
| 35i 3.0 AT xDrive | Gasoline | 2979 cm³ | 306 hp | 225 kW | 400 N⋅m | Automatic | AWD |
BMW X4 Dimensions
SUV 5-doors — BMW X4 Dimensions
| Modification | Length | Width | Height | Wheelbase | Curb weight | Max weight | Ground clearance, minimum |
|---|---|---|---|---|---|---|---|
| 30d 3.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1820 kg | 2410 kg | 204 mm |
| 35d 3.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1860 kg | 2440 kg | 204 mm |
| M40i 3.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1840 kg | 2430 kg | 204 mm |
| 20d 2.0 MT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1805 kg | 2320 kg | 204 mm |
| 20d 2.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1730 kg | 2320 kg | 204 mm |
| 30d 3.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1820 kg | 2410 kg | 204 mm |
| 20i 2.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1735 kg | 2325 kg | 204 mm |
| 28i 2.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1770 kg | 2360 kg | 204 mm |
| 35i 3.0 AT xDrive | 4671 mm | 1881 mm | 1624 mm | 2810 mm | 1815 kg | 2405 kg | 204 mm |
BMW X4 Cargo Space
SUV 5-doors — BMW X4 Cargo Space
| Modification | Trunk volume min | Trunk volume max |
|---|---|---|
| 30d 3.0 AT xDrive | 500 l | 1400 l |
| 35d 3.0 AT xDrive | 500 l | 1400 l |
| M40i 3.0 AT xDrive | 500 l | 1400 l |
| 20d 2.0 MT xDrive | 500 l | 1400 l |
| 20d 2.0 AT xDrive | 500 l | 1400 l |
| 30d 3.0 AT xDrive | 500 l | 1400 l |
| 20i 2.0 AT xDrive | 500 l | 1400 l |
| 28i 2.0 AT xDrive | 500 l | 1400 l |
| 35i 3.0 AT xDrive | 500 l | 1400 l |
BMW X4 Trims and Equipment
BMW X4 trim levels help you distinguish equipment choices within a technical version. The diesel automatic 20d 2.0 AT xDrive has configurations named xDrive20d and xDrive20d M Sport (Local Assembly). The M Sport label does not itself indicate a different engine; check the individual car’s seats, parking aids and fitted options against your needs.
| Modification | Body | Equipment |
|---|---|---|
| 30d 3.0 AT xDrive | SUV 5-doors | xDrive20d |
| 30d 3.0 AT xDrive | SUV 5-doors | xDrive28i Exclusive (Local Assembly) |
| 35d 3.0 AT xDrive | SUV 5-doors | xDrive35i |
| M40i 3.0 AT xDrive | SUV 5-doors | M40i |
| 20d 2.0 MT xDrive | SUV 5-doors | xDrive20d |
| 20d 2.0 AT xDrive | SUV 5-doors | xDrive20d |
| 20d 2.0 AT xDrive | SUV 5-doors | xDrive20d M Sport (Local Assembly) |
| 20d 2.0 AT xDrive | SUV 5-doors | Sport |
| 30d 3.0 AT xDrive | SUV 5-doors | Luxury |
| 20i 2.0 AT xDrive | SUV 5-doors | xDrive20d |
| 20i 2.0 AT xDrive | SUV 5-doors | xDrive20d M Sport (Local Assembly) |
| 20i 2.0 AT xDrive | SUV 5-doors | Sport |
| 28i 2.0 AT xDrive | SUV 5-doors | xDrive20d |
| 28i 2.0 AT xDrive | SUV 5-doors | xDrive28i Exclusive (Local Assembly) |
| 28i 2.0 AT xDrive | SUV 5-doors | Sport |
| 35i 3.0 AT xDrive | SUV 5-doors | xDrive35i |
