Catalog / Audi / A3 / 2 generation, restyling 2
Audi A3 Engines and Transmissions
Audi A3 engine options span small turbocharged petrol units and economical diesels. A 1.4 MT Cabrio with a manual gearbox and front-wheel drive suits relaxed driving, while a 1.6 AT Cabrio adds an automatic. The 2.0 S-tronic three-door diesel combines a fast-shifting robotic transmission with all-wheel drive for extra traction.
Cabrio — Audi A3 Engines and Transmissions
Cabrio Audi A3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.4 MT Gasoline 1390 cm³ 125 hp 92 kW 200 N⋅m Manual FWD 1.6 S-tronic Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Robotic FWD 1.6 MT Diesel 1598 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 1.8 MT Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Manual FWD 1.6 AT Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Automatic FWD 2.0 S-tronic Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Robotic FWD 1.2 MT Gasoline 1197 cm³ 105 hp 77 kW 175 N⋅m Manual FWD 1.6 MT Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual FWD 2.0 MT Gasoline 1968 cm³ 200 hp 147 kW 280 N⋅m Manual FWD 1.8 S-tronic Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Robotic FWD 2.0 S-tronic Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Robotic FWD
Hatchback 5-door — Audi A3 Engines and Transmissions
Hatchback 5-door Audi A3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.8 MT Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Manual FWD 2.0 S-tronic Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Robotic AWD 3.2 S-tronic Gasoline 3189 cm³ 250 hp 184 kW 320 N⋅m Robotic AWD 1.6 S-tronic Diesel 1598 cm³ 105 hp 77 kW 250 N⋅m Robotic FWD 1.9 MT Diesel 1896 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual AWD 2.0 MT Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Manual AWD 2.0 S-tronic Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Robotic FWD 2.0 MT Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Manual FWD 1.2 MT Gasoline 1197 cm³ 105 hp 77 kW 175 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 125 hp 92 kW 200 N⋅m Manual FWD 1.6 MT Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Manual FWD 1.6 MT Diesel 1598 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 105 hp 78 kW 250 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual FWD 2.0 MT Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Manual FWD 1.8 MT Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Manual AWD 2.0 MT Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Manual AWD 1.6 MT Diesel 1598 cm³ 90 hp 66 kW 230 N⋅m Manual FWD 1.6 MT Diesel 1598 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 1.9 S-tronic Diesel 1896 cm³ 105 hp 77 kW 250 N⋅m Robotic FWD 2.0 S-tronic Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Robotic FWD 1.2 S-tronic Gasoline 1197 cm³ 105 hp 77 kW 175 N⋅m Robotic FWD 1.4 S-tronic Gasoline 1390 cm³ 125 hp 92 kW 200 N⋅m Robotic FWD 1.8 S-tronic Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Robotic FWD 2.0 S-tronic Gasoline 1968 cm³ 200 hp 147 kW 280 N⋅m Robotic FWD 3.2 MT Gasoline 3189 cm³ 250 hp 184 kW 320 N⋅m Manual AWD 2.0 S-tronic Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Robotic FWD 2.0 S-tronic Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Robotic FWD 1.6 S-tronic Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Robotic FWD
Hatchback 3-door — Audi A3 Engines and Transmissions
Hatchback 3-door Audi A3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.2 MT Gasoline 1197 cm³ 105 hp 77 kW 175 N⋅m Manual FWD 2.0 MT Gasoline 1968 cm³ 200 hp 147 kW 280 N⋅m Manual FWD 1.6 MT Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Manual FWD 1.8 MT Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Manual AWD 2.0 MT Gasoline 1968 cm³ 200 hp 147 kW 280 N⋅m Manual AWD 1.6 MT Diesel 1598 cm³ 90 hp 66 kW 230 N⋅m Manual FWD 1.6 MT Diesel 1598 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 1.9 S-tronic Diesel 1896 cm³ 105 hp 77 kW 250 N⋅m Robotic FWD 1.9 MT Diesel 1896 cm³ 105 hp 77 kW 250 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 125 hp 92 kW 200 N⋅m Manual FWD 1.8 MT Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Manual FWD 2.0 S-tronic Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Robotic AWD 3.2 MT Gasoline 3189 cm³ 250 hp 184 kW 320 N⋅m Manual AWD 1.6 S-tronic Diesel 1598 cm³ 105 hp 77 kW 250 N⋅m Robotic FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual FWD 2.0 MT Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Manual AWD 2.0 MT Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Manual FWD 2.0 S-tronic Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Robotic FWD 2.0 MT Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Manual AWD 2.0 S-tronic Diesel 1968 cm³ 170 hp 125 kW 350 N⋅m Robotic AWD 1.2 S-tronic Gasoline 1197 cm³ 105 hp 77 kW 175 N⋅m Robotic FWD 1.4 S-tronic Gasoline 1390 cm³ 125 hp 92 kW 200 N⋅m Robotic FWD 1.8 S-tronic Gasoline 1798 cm³ 160 hp 118 kW 250 N⋅m Robotic FWD 2.0 S-tronic Gasoline 1984 cm³ 200 hp 147 kW 280 N⋅m Robotic FWD 1.6 S-tronic Gasoline 1595 cm³ 102 hp 75 kW 148 N⋅m Robotic FWD 3.2 S-tronic Gasoline 3189 cm³ 250 hp 184 kW 320 N⋅m Robotic AWD 2.0 S-tronic Diesel 1968 cm³ 140 hp 103 kW 320 N⋅m Robotic FWD
Audi A3 Dimensions
Cabrio — Audi A3 Dimensions
Cabrio Audi A3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.4 MT 4238 mm 1765 mm 1424 mm 2578 mm 1285 kg 1860 kg 140 mm 1.6 S-tronic 4238 mm 1765 mm 1424 mm 2578 mm 1260 kg 1820 kg 140 mm 1.6 MT 4238 mm 1765 mm 1424 mm 2578 mm 1320 kg 1880 kg 120 mm 1.8 MT 4238 mm 1765 mm 1424 mm 2578 mm 1425 kg 1925 kg 140 mm 1.6 AT 4238 mm 1765 mm 1424 mm 2578 mm Not provided Not provided 120 mm 2.0 S-tronic 4238 mm 1765 mm 1424 mm 2578 mm 1475 kg 1975 kg 140 mm 1.2 MT 4238 mm 1765 mm 1424 mm 2578 mm 1280 kg 1765 kg 140 mm 1.6 MT 4238 mm 1765 mm 1424 mm 2578 mm 1205 kg 1765 kg 140 mm 1.9 MT 4238 mm 1765 mm 1424 mm 2578 mm 1280 kg 1840 kg 140 mm 2.0 MT 4238 mm 1765 mm 1424 mm 2578 mm 1340 kg 1900 kg 140 mm 2.0 MT 4238 mm 1765 mm 1424 mm 2578 mm 1360 kg 1920 kg 140 mm 1.8 S-tronic 4238 mm 1765 mm 1424 mm 2578 mm 1450 kg 1950 kg 140 mm 2.0 S-tronic 4238 mm 1765 mm 1424 mm 2578 mm 1370 kg 1930 kg 140 mm
Hatchback 5-door — Audi A3 Dimensions
Hatchback 5-door Audi A3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.8 MT 4286 mm 1765 mm 1423 mm 2578 mm 1345 kg 1905 kg 140 mm 2.0 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1455 kg 2015 kg 140 mm 3.2 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1535 kg 2095 kg 140 mm 1.6 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1435 kg 1910 kg 120 mm 1.9 MT 4286 mm 1765 mm 1423 mm 2578 mm 1335 kg 1895 kg 140 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1380 kg 1940 kg 140 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1470 kg 2030 kg 140 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1380 kg 1940 kg 140 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1480 kg 2040 kg 140 mm 2.0 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1410 kg 1970 kg Not provided 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1435 kg 1935 kg 140 mm 1.2 MT 4286 mm 1765 mm 1423 mm 2578 mm 1360 kg 1860 kg 140 mm 1.4 MT 4286 mm 1765 mm 1423 mm 2578 mm 1410 kg 1910 kg 140 mm 1.6 MT 4286 mm 1765 mm 1423 mm 2578 mm 1330 kg 1830 kg 140 mm 1.6 MT 4286 mm 1765 mm 1423 mm 2578 mm 1430 kg 1930 kg 140 mm 1.9 MT 4286 mm 1765 mm 1423 mm 2578 mm 1425 kg 1925 kg 140 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1475 kg 1975 kg 140 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1320 kg 1880 kg 140 mm 1.8 MT 4286 mm 1765 mm 1423 mm 2578 mm 1380 kg 1865 kg 120 mm 2.0 MT 4286 mm 1765 mm 1423 mm 2578 mm 1430 kg 1990 kg 140 mm 1.6 MT 4286 mm 1765 mm 1423 mm 2578 mm 1280 kg 1840 kg 140 mm 1.6 MT 4286 mm 1765 mm 1423 mm 2578 mm 1280 kg 1840 kg 140 mm 1.9 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1320 kg 1880 kg 140 mm 2.0 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1370 kg 1930 kg 140 mm 1.2 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1345 kg 1870 kg 140 mm 1.4 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1285 kg 1860 kg 140 mm 1.8 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1335 kg 1895 kg 140 mm 2.0 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1360 kg 1920 kg 140 mm 3.2 MT 4286 mm 1765 mm 1423 mm 2578 mm 1535 kg 2095 kg 140 mm 2.0 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1485 kg 1940 kg 120 mm 2.0 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm 1435 kg 1935 kg 140 mm 1.6 S-tronic 4286 mm 1765 mm 1423 mm 2578 mm Not provided Not provided 120 mm
Hatchback 3-door — Audi A3 Dimensions
Hatchback 3-door Audi A3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.2 MT 4214 mm 1765 mm 1421 mm 2578 mm 1320 kg 1870 kg 140 mm 2.0 MT 4214 mm 1765 mm 1421 mm 2578 mm 1360 kg 1920 kg 140 mm 1.6 MT 4214 mm 1765 mm 1421 mm 2578 mm 1245 kg 1805 kg 140 mm 1.8 MT 4214 mm 1765 mm 1421 mm 2578 mm Not provided Not provided 120 mm 2.0 MT 4214 mm 1765 mm 1421 mm 2578 mm 1470 kg 2030 kg 140 mm 1.6 MT 4214 mm 1765 mm 1421 mm 2578 mm 1320 kg 1880 kg 120 mm 1.6 MT 4214 mm 1765 mm 1421 mm 2578 mm 1320 kg 1880 kg 120 mm 1.9 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1435 kg 1910 kg 120 mm 1.9 MT 4214 mm 1765 mm 1421 mm 2578 mm 1335 kg 1895 kg 120 mm 1.4 MT 4214 mm 1765 mm 1421 mm 2578 mm 1245 kg 1820 kg 140 mm 1.8 MT 4214 mm 1765 mm 1421 mm 2578 mm 1305 kg 1865 kg 140 mm 2.0 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1415 kg 1975 kg 140 mm 3.2 MT 4214 mm 1765 mm 1421 mm 2578 mm 1495 kg 2055 kg 140 mm 1.6 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1300 kg 1860 kg 140 mm 2.0 MT 4214 mm 1765 mm 1421 mm 2578 mm 1340 kg 1900 kg 140 mm 2.0 MT 4214 mm 1765 mm 1421 mm 2578 mm 1430 kg 1990 kg 140 mm 2.0 MT 4214 mm 1765 mm 1421 mm 2578 mm 1340 kg 1900 kg 140 mm 2.0 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1370 kg 1930 kg 140 mm 2.0 MT 4214 mm 1765 mm 1421 mm 2578 mm 1440 kg 2000 kg 140 mm 2.0 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm Not provided 1930 kg 120 mm 1.2 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1290 kg 1775 kg 140 mm 1.4 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1245 kg 1820 kg 140 mm 1.8 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1335 kg 1895 kg 140 mm 2.0 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1370 kg 1930 kg 140 mm 1.6 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1220 kg 1780 kg 140 mm 3.2 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1525 kg 2085 kg 140 mm 2.0 S-tronic 4214 mm 1765 mm 1421 mm 2578 mm 1475 kg 1975 kg 140 mm
Audi A3 Cargo Space
Cabrio — Audi A3 Cargo Space
Hatchback 5-door — Audi A3 Cargo Space
Hatchback 3-door — Audi A3 Cargo Space
Audi A3 Trims and Equipment
Audi A3 trim levels sit on top of each technical version, so the same mechanical package can be specified very differently. The 1.2 S-tronic five-door hatchback, for example, comes as Base or Ambition. Base covers the essentials; Ambition typically adds sportier seats, wheels and interior detailing rather than changing the drivetrain.
