Alfa Romeo 147 Specs, Engines & Dimensions (2004–2010) — First Generation Restyling

The facelifted Alfa Romeo 147 comes in three-door and five-door hatchback forms. If you regularly carry rear passengers, the five-door layout makes access easier, while your powertrain choice shapes how the car feels to drive.

← All Alfa Romeo models

Alfa Romeo 147 Engines and Transmissions

Selected Alfa Romeo 147 engine and transmission choices include the gasoline 3.2 MT and 2.0 MT manuals, plus the 2.0 TCT with a robotic gearbox. These three-door examples all use front-wheel drive. The manuals give you direct clutch control, while the robotic transmission handles clutch operation and can change gears automatically.

Hatchback 3-door — Alfa Romeo 147 Engines and Transmissions

Hatchback 3-door Alfa Romeo 147 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	120 hp	88 kW	146 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	101 hp	74 kW	199 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	115 hp	85 kW	275 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	120 hp	88 kW	280 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	140 hp	103 kW	305 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	150 hp	110 kW	305 N⋅m	Manual	FWD
3.2 MT	Gasoline	3179 cm³	250 hp	184 kW	300 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	136 hp	100 kW	Not provided	Manual	FWD
1.9 MT	Diesel	1910 cm³	170 hp	125 kW	Not provided	Manual	FWD
2.0 TCT	Gasoline	1970 cm³	150 hp	110 kW	181 N⋅m	Robotic	FWD
2.0 MT	Gasoline	1970 cm³	150 hp	110 kW	181 N⋅m	Manual	FWD
1.6 MT	Gasoline	1598 cm³	105 hp	77 kW	140 N⋅m	Manual	FWD

Hatchback 5-door — Alfa Romeo 147 Engines and Transmissions

Hatchback 5-door Alfa Romeo 147 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1598 cm³	120 hp	88 kW	146 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	101 hp	74 kW	199 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	115 hp	85 kW	275 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	120 hp	88 kW	280 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	136 hp	100 kW	Not provided	Manual	FWD
1.9 MT	Diesel	1910 cm³	140 hp	103 kW	305 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	150 hp	110 kW	305 N⋅m	Manual	FWD
1.9 MT	Diesel	1910 cm³	170 hp	125 kW	Not provided	Manual	FWD
2.0 TCT	Gasoline	1970 cm³	150 hp	110 kW	181 N⋅m	Robotic	FWD
2.0 MT	Gasoline	1970 cm³	150 hp	110 kW	181 N⋅m	Manual	FWD
1.6 MT	Gasoline	1598 cm³	105 hp	77 kW	140 N⋅m	Manual	FWD

Alfa Romeo 147 Dimensions

Hatchback 3-door — Alfa Romeo 147 Dimensions

Hatchback 3-door Alfa Romeo 147 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4223 mm	1729 mm	1442 mm	2546 mm	1225 kg	1720 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1270 kg	1790 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1270 kg	1790 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1795 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
3.2 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1795 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
2.0 TCT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1770 kg	120 mm
2.0 MT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1770 kg	120 mm
1.6 MT	4223 mm	1729 mm	1442 mm	2546 mm	1190 kg	1710 kg	120 mm

Hatchback 5-door — Alfa Romeo 147 Dimensions

Hatchback 5-door Alfa Romeo 147 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4223 mm	1729 mm	1442 mm	2546 mm	1225 kg	1720 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1270 kg	1790 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1270 kg	1790 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1795 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1795 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
1.9 MT	4223 mm	1729 mm	1442 mm	2546 mm	1290 kg	1819 kg	120 mm
2.0 TCT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1770 kg	120 mm
2.0 MT	4223 mm	1729 mm	1442 mm	2546 mm	1275 kg	1770 kg	120 mm
1.6 MT	4223 mm	1729 mm	1442 mm	2546 mm	1190 kg	1710 kg	120 mm

Alfa Romeo 147 Cargo Space

Hatchback 3-door — Alfa Romeo 147 Cargo Space

Hatchback 3-door Alfa Romeo 147 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
3.2 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
2.0 TCT	292 l	1042 l
2.0 MT	292 l	1042 l
1.6 MT	292 l	1042 l

Hatchback 5-door — Alfa Romeo 147 Cargo Space

Hatchback 5-door Alfa Romeo 147 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
1.9 MT	292 l	1042 l
2.0 TCT	292 l	1042 l
2.0 MT	292 l	1042 l
1.6 MT	292 l	1042 l

Alfa Romeo 147 Trims and Equipment

Alfa Romeo 147 Trims and Equipment
Modification	Body	Equipment
1.6 MT	Hatchback 3-door	Progression
1.6 MT	Hatchback 5-door	TS
1.6 MT	Hatchback 5-door	Progression
